3W/5W/8W Factory Direct Visual Positioning Laser Marking Machine Laser Marker UV Laser Marking Machine
Ningbo Zhen Yue Machinery Co., Ltd.- After-sales Service：Online Sales After Service
- Warranty：2 Years
- Laser Visibility：Visible
- Applicable Material：Nonmetal
- Cooling System：Water Cooling
- Technical Class：Pulse Laser
Base Info
- Model NO.：HR-Z3s
- Laser Wavelength：Deep Ultraviolet
- Laser Classification：Solid Laser
- Type：UV Laser
- Marking Method：Scanning Marking
- Output Power：3W
- Working Area：175*175mm(Customized)
- Cooling：Water Cooling
- Overall Weight：160kg
- Working Life：100000hours
- Transport Package：Standard Export Plywood Cases
- Specification：sheet metal + precision accessories
- Trademark：HAIRONG
- Origin：China
- HS Code：8456100090
- Production Capacity：300units,Month
Description
Output Power
3W
5W
8W
Operation Mode
Pulsed
Pulsed
Pulsed
Pulse Repetition Rate
10-120kHz
10-120kHz
10-120kHz
Single Pulse Output Energy at 20kHz
1.0MJ
1.0MJ
1.0MJ
Pulse Width
<25ns
<25ns
<25ns
Peak Power of the Pulse at 20kHz
>20/10kW
>20/10kW
>20/10kW
Adjustment Range of the Output power
10 - 100%
10 - 100%
10 - 100%
Output Power Stability
<+/- 2, %
<+/- 2, %
<+/- 2, %
Laser Wavelength
355nm
355nm
355nm
Marketing Area
175x175 mm(customized)
175x175 mm(customized)
175x175 mm(customized)
Scanning Speed
Max 10 m/sec
Max 10 m/sec
Max 10 m/sec
Storage Temperature
- 20 to + 60°C
- 20 to + 60°C
- 20 to + 60°C
Operating Ambient Temperature
+ 5 to + 40 °C
+ 5 to + 40 °C
+ 5 to + 40 °C
Input Voltage(Double Insulation Protection)
220VAC
220VAC
220VAC
Input Electric Power
<500W
<500W
<500W
Cooling
Water Cooling
Water Cooling
Water Cooling
Overall Weight
160kg
160kg
160kg
Full-load power consumption of the whole machine
1.5kw/h
1.5kw/h
1.5kw/h
Working Life
100000hours
100000hours
100000hours
3.Product Superiority
1)The laser wavelength is 355nm UV which will form very small spot(cold light). Therefore, it can greatly reduce the mechanical deformation of materials.
2)Unlike before, small-size products can also be marked or welded by laser machine. With the use of vision positioning system, the "small part" can be enlarged to "big part". As in the past, accuracy is hard to be controlled for the traditional marking machine, but it will no longer be a problem for the UV laser marking machine.
3)Marking accuracy is no longer restricted by fixture accuracy. With the visual positioning system, the laser marking machine can mark precisely. At this time, the marking accuracy has nothing to do with the fixture.
4)The angle and position of product placement are no longer constrained. No other requirements except place the product within the light output range of the laser machine lens.
4.Application Fields
The laser wavelength is 355nm UV which will form very small spot(cold light). Therefore, it can greatly reduce the mechanical deformation of materials. It is mainly used for ultra-fine marking and engraving. It is very suitable for the marking and micropores of food, pharmaceutical packaging materials, glass materials and complex graphic cutting of silicon wafers.
5.Marking Sample
6.Our Company
7.Our Factory
8.Exhibition
