• Model NO.：PEDB-400
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Carving Material：Stainless Steel
• Standard Marking Area：110mm * 110mm
• Weight：60kg
• Laser Power：10W, 20W
• Working Table：Manuel up and Down Aluminium Alloy Working Table
• Size：0.05cbm
• Fiber Laser Device Lifetime：100, 000
• Optional：175X175mm
• Laser Device：Fiber Laser Device
• Transport Package：Wooden Cases with Exporting Standard
• Specification：ISO 9001 & CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：9013200090
• Production Capacity：3000 Unit , Year

Machine TypeFiber Laser Marking MachineLaser SoursePEDB-400  10W  PEDB-400  20WIPG SeriesPulsed, High Energy Ytterbium Fiber LasersMode of operation                                      PulsedPolarization                        randomQ-switched operationOutput power adjustment range10%-100%Nominal average output power W10W20WCentral emission wavelength    1060-1070 nmEmission Bandwidth (FWHM)  < 10 nmLong-term average power instability< 5%Pulse width, (FWHM)                          100 nsLaser switching ON time                    180 μ secLaser switching OFF time            180 μ secPulse Repetition Rate* kHz                20-80 kHzEnergy per pulse (PRR = 20 kHz)0.95 mJTypical beam quality, M2                        < 1.8Output fiber delivery length              3mOperating voltage                                    220VMax. Power consumption    600W



  --------------------------------------------------------------------------------------
Perfect Laser Co., Ltd. (China)
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Hubei, China(430200)
