• Model NO.：1325
• Laser Source：Sealed CO2 Laser Tube 300W
• Auxiliary Air for Metals：Nitrogen, Oxygen, Air
• Laser Head：Follow-up Laser Head
• Working Table：Blade
• Position Accuracy：±0.05mm
• Compatible Format：BMP, Plt, Dst, Ai, Dxf etc
• Working Voltage：220V±10% 50Hz or 110V±10% 60Hz
• Software Supported：Coreldraw, Autocad(Direct Output)
• Main Graphic Format Supported：Plt,Dxf,Dst,BMP,Ai etc. (Direct Output)
• Standard Parts：Knife Working Table with Funnel
• Transport Package：385*220*130cm
• Trademark：MINDER
• Origin：China
• HS Code：8456110090
• Production Capacity：100pieces,Month

Basic Info.

Model NO. 1325 Laser Source Sealed CO2 Laser Tube 300W Auxiliary Air for Metals Nitrogen, Oxygen, Air Laser Head Follow-up Laser Head Working Table Blade Position Accuracy ±0.05mm Compatible Format BMP, Plt, Dst, Ai, Dxf etc Working Voltage 220V±10% 50Hz or 110V±10% 60Hz Software Supported Coreldraw, Autocad(Direct Output) Main Graphic Format Supported Plt/Dxf/Dst/BMP/Ai etc. (Direct Output) Standard Parts Knife Working Table with Funnel Transport Package 385*220*130cm Trademark MINDER Origin China HS Code 8456110090 Production Capacity 100pieces/Month

Product Description

Introduction
1325 machine is a mixing cutting machine, specialized in cutting stainless steel,
carbon steel, MDF, die board and wood.
1325 machine is matched with the stepper motor system to ensure high precision.
Machine with gear rack ensure the high precision, running stable and long-operation.
The sheet metal is not flat. But the system can sense a distance from the nozzle
to the metal surface and follow the surface up and down to automatically adjust the
certain focus distance for keeping high precision cutting quality.
High efficiency, high precision, stable performance and long life.Low running cost
about 5KVA/hour.
Features
Laser tube (300W )High precision ball-screw system 300W
Application Material
Stainless steel, carbon steel, galvanized steel, acrylic, plywood, MDF and other
materials.
Application Industry
Advertising industry(stainless steel and acrylic), sheet metal industry, packaging
industry, arts and crafts, awards and trophies, paper-cutting, architectural models,
lights and lamps, electronic appliance, photo frame and album, garment leather and
other industries.
Technical parameters

Mode	1325
Working area	1300*2500mm
Laser source	Sealed co2 laser tube 300W
Auxiliary air for metals	Nitrogen, Oxygen, Air ,,
Laser head	Follow-up laser head
Working table	Blade
Position accuracy	±0.05mm
Compatible format	BMP, PLT, DST, AI, DXF etc
Cooling mode	Constant temperature water cooling and protection system
Working voltage	220V±10% 50Hz or 110V±10% 60Hz
Software supported	CorelDraw, AutoCAD(Direct output)
Main Graphic format supported	PLT/DXF/DST/BMP/AI etc. (Direct output)
Standard Parts	1)Knife working table with funnel 2) Air compressor 3) Exhaust fans 4) Standard cooling system CW6000 5) Tool box
Support	By calling or email or training ,,

If you need more further details about our machines,  please feel free to contact us .
