Hand Held Portable Jpt Raycus Ipg 1000W 1500W Stainless Steel Fiber Laser Welding Machine
Jinan Laser Max Machinery Tech Co., Ltd.- After-sales Service：Online Aftersales Service
- Warranty：3years
- Application：Biomedicine, Electronic Industry, Automotive Industry, Powder Metallurgy, Manufacturing Industry
- Technical Class：Pulse Laser
- Control：Automatic
- Laser Classification：Optical Fiber Laser
Base Info
- Transport Package：Wooden Packing
- Specification：1230*900*1250mm
- Trademark：LM
- Origin：Jinan, China
- HS Code：8456110090
- Production Capacity：50000 Set, Year
Description
NO.
Name
Parameter
1
Machine model
Hand-held fiber laser welding machine
2
Laser source
Raycus
3
laser power
1000W,1500W
4
laser wave length
1070 NM
5
Uptime
24 hours
6
operate mode
continuation/ modulate
7
Welding speed range
0~120 mm/s
8
Laser pulse width
0.1-20ms
9
Cooling chiller
Industrial water chiller
10
Working environment temperature range
15~35 ºC
11
Humidity range of working environment
< 70% No condensation
12
Welding thickness recommendations
0.5-3mm
13
Welding gap requirements
≤0.5mm
14
working voltage
220 V
15
Dimensions
1140*670*1400 mm
16
Weight
270kg
