• Model NO.：GS-CE
• Laser Technology：Laser Control Fault Cutting
• Laser Type：CNC Fiber
• Manufacturer：Dongguan, China
• Brand：Glorystar
• Machine Working Area：2500X1300mm, 3000X1500mm, 4000X2000mm
• Applied Materials：Stainless Steel, Carbon Steel, Galvanized Sheet
• Product Name：Fiber Laser Cutting Machine for Carbon Steel
• Color：Red and White
• Working Area：3000*1500mm and Optional
• Control System：Optional
• Drag Chain Tow：Import
• Transport Package：Packaged by Plywood
• Specification：CE, ISO, FDA, BV
• Trademark：GLORYSTAR
• Origin：China
• HS Code：8456100090
• Production Capacity：1000sets,Year

13000*3000X-axis working stroke (mm)3080Y-axis working stroke (mm)13100Z-axis working stroke (mm)150X/Y-axis positioning accuracy±0.05mm/mX/Y-axis repeated positioning accuracy≤0.03mmMaximum synthetic positioning speed140m/minMaximum acceleration2.1GSlit's width0.1-0.5mm(Measured value below 3mm thickness)Slit's roughnessRa3.2-Ra25.4(Measured value below 3mm thickness)Maximum cutting thickness rangeRefer to the craft parameter tableMinimum setting unit0.001mmCovering area of machine tool (mm)17000*7000Host volume (mm)16500*5250*2000CNC systemCpyCutMonitor27″LCDDriving modeGear rack dual driveMaximum bearing capacity of worktable (T)18Machine weight (T)20Total installed power consumption (approximately)Laser Power:8000W80kWLaser Power:12000W120kWLaser Power:15000W150KWLaser Power:20000W200KWLaser Power:30000W300KWPower requirementsAC380V,50Hz;3P+N+PETotal power protection levelIP54
Glorystar Laser · Global laser smart solution expert

Glorystar Laser Group has been deeply engaged in the manufacturing of laser intelligent equipment for 11 years. It is headquartered in Dongguan, China and has two wholly-owned subsidiaries.It is a national high-tech enterprise focusing on laser application solutions such as laser cutting, tube cutting, precision cutting, laser welding, laser marking, CNC bending, and automation equipment.
Glorystar Laser has established branches and service outlets in 30% of the countries and regions around the world to promote the process of global intelligence and has more than 200 patents and certificates. Glorystar Laser adheres to the quality route and forms 139 production and inspection procedures higher than the industry standard. With the mission of "Laser technology makes a better world", its high-quality products and after-sales service have won high praise from customers.


After-sale Sevice

<<< We offer professional after-sales installation and  guidance, after-sales online. we can be remotely controlled by teamviwer, to help customers solve the problem.

<<< For on-line not solve the problem, we will arrange technical personnel to the customer's company offer after-sales service

 <<<Equipment warranty period of one year, optical lenses can not be maintained. Laser generator has 12months warranty, machine maintenance of life.

Agent wanted all over the world!

We are in top 3 laser manufacture in China,our main products are fiber laser cutting machine ,Co2 laser cutting machine ,laser marking machine ,laser welding machine and CNC bending machine.We are specially for laser technology for more than 15 years,we have our research and development department. now we have more than 300 employees.
May I know more about your company and your product information?
What is the main material do you want to cut?what is the max thickness of it? What is the industry it will applied to ? looking forward to your early reply .
Many thanks & Best regards.
