20W 1064nm Wave Small Laser Marking Machine for Metal Plastic
Shandong Man Machinery Equipment Co., Ltd.- Laser Visibility：Invisible
- Applicable Material：Metal
- Cooling System：Air Cooling
- Technical Class：Pulse Laser
- Laser Wavelength：Fiber Laser
- Laser Classification：Semiconductor Laser
Base Info
- Model NO.：MAN-20
- Type：Optical Fiber Laser Marking Machine
- Marking Method：Scanning Marking
- Model：20W,30W
- Marking Area：110mmx110mm;
- Repeat Frequency：10kHz- 100kHz
- Voltage：220V,50Hz
- Markingspeed：7000mm
- Marking Depth：0-0.5mm
- Positioning Way：Red Light
- Cooling Mode：Air Cooling
- Software：Ezcad Software
- Certification：Ce FDA
- Transport Package：Wooden Box
- Specification：860*360*760mm
- Trademark：CNMANLASER
- Origin：Shandong
- HS Code：8456110090
- Production Capacity：500 Set,Month
Description
1
What materials you want to process with?( stainless steel, aluminum, wood, plastic...)
2
Effective marking size? (75*75mm, 110*110mm, 175*175mm, 300*300mm)
3
Do you need to mark on cylindrical or round surface?
4
Do you have size or weight of the product you need to mark on?
5
Do you buy for personal use or selling?
| Model | MAN-10W/ MAN-20W/ MAN-30W |
| Laser power | 10W 20W 30W 50W |
| Laser wavelength | 1064nm |
| Power adjustment range | 10-100% |
| Repetition frequency | 20-100KHz |
| Output beam quality | <1.5M² |
| Marking Linear deep | ≤1.2mm |
| Min. Highlight spot | 0.005mm |
| Min. character size high | 0.15mm |
| Repetition accuracy | ±0.001mm |
| Max. Linear marking speed | 12000mm/s |
| Standard marking area | 100mm×100mm |
| Marking area option | 150mm×150mm 200mm×200mm |
| Power consumed | ≤160W |
| Electrical demand | 220V±10%/50Hz/4A |
| Cooling Mode | Air-cooled |
| Control interface | USB |
| Laser module life | >10000 hours |
| Resonance mirror | high speed |
| Ambient operating temperature | 15 ° C - 35 ° C |
| Operating voltage | 110/220V ± 10% /,50/60HZ |
| Weight | 60KG |
| Dimensions | 600H * 200W * 700L (mm ) |
| Packing | plywood wooden packaging |
Main Advantage of the laser machine :
Compact: The high-tech product, which is combined of laser device, computer, integral structure.
Laser power:20W / 30W / 50W
High Precision: Re-position precision is 0.001mm
High Speed: Imported scanning system makes the scanning speed is up to 7m/s
Easily Operating: Afford the specific marking software based on Windows, which is real-time adjust the laser power and pulse frequency.
You can input and output by computer according to edit in the both of the specific marking software and the graphic software such as jpg, jpeg,.
High Stability: Laser mould life :120000 hours
Energy Saving: The efficiency of optic-electrical converting is up to 30%
Low Running Cost: No wearing part. Free maintaining.
Other advantages: small volume, easy transportation, low energy consumption
SAMPLE SHOW :
Marking content
Jewelry making machine can mark logo, character, serial number, bar code, data matrix on both metals and some non-metals.
Applicable Materials
Metals and alloys (carbon steel/mild steel, stainless steel, aluminum, copper, magnesium, zinc, etc.), rare metal and alloy steel (gold, silver, titanium, etc.)
and some non-metal (plastic, PMMA, etc.), special surface treatment (aluminum anodized, plating surface, surface oxygen breaking of aluminum a
nd magnesium alloy).
Applicable Industries
Electronic components, IC, electrical appliances, mobile phones, plastic buttons, color paper, food packaging, clocks and watches, molding, gaskets
and seals, bearing, auto parts, hardware, tools, building materials, PVC tubes.
PACKAGING & SHIPPING :
FAQ :
Q1. How to get the most suitable machine and best price
Please tell us the material you want to king on ? How to working on it ? Engraving ? Cutting ? Marking Or other ?
What's the MAX size of these material ?( length ? Width ? Thickness ?)
Q2. How to use the machine? And How about your after-sales service?
Sure, the machine installation,operation and training instruction CD video are delivered along with the machine.. you can learn how to use it well.
And on line 24 hours technical people teach you directly via call, computer remote control, skype video etc.
So, don't worry even you are a beginner on the machine.
Q3 Guarantee and Quality Control :
3 years guarantee
The whole production procedure will be under regular inspection and strict quality control.
The complete machine will be tested to make sure they can work very well before being out of factory.
Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.
Q4. How we pay you?
Before you place order, you'd better confirm machine details with us, then you can pay by TT,Western union, Paybal, Alipay etc.
Q5:How about the documents after shipment?
After shipment, we'll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L,
and other certificates as required by clients.
Q6:How long is the delivery time?
For standard machines, it would be 3-7 days;
For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
