• Model NO.：HJZ-CDB
• Laser Wavelength：CO2 Laser
• Laser Classification：Gaseous Laser
• Type：CO2 Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Output Power：20W, 30W, 50W
• Engraving Speed：9000mm,S
• Operating Voltage：110-240V
• Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf, Dxp
• Marking Area：110*110mm, 175*175mm, 220*220mm, 300*300mm
• Certification：CE.FDA
• Condition：New
• Application Material：0.1-2mm
• Process Material：Metal and Some Non-Metal
• Delivery Time：1-3days
• Laser Source：Synrad
• Lifespan：Over 20, 000hours
• Control Software：Ezcad Software
• Transport Package：Standard Plywood Packing for Export
• Specification：1650X1250X1050MM
• Trademark：HJZ
• Origin：Wuhan, China
• HS Code：84561000
• Production Capacity：20sets,Month

Basic Info.

Model NO. HJZ-CDB Laser Wavelength CO2 Laser Laser Classification Gaseous Laser Type CO2 Laser Marking Machine Marking Method Scanning Marking Laser Output Power 20W, 30W, 50W Engraving Speed 9000mm/S Operating Voltage 110-240V Graphic Format Supported Ai, BMP, Dst, Dwg, Dxf, Dxp Marking Area 110*110mm, 175*175mm, 220*220mm, 300*300mm Certification CE.FDA Condition New Application Material 0.1-2mm Process Material Metal and Some Non-Metal Delivery Time 1-3days Laser Source Synrad Lifespan Over 20, 000hours Control Software Ezcad Software Transport Package Standard Plywood Packing for Export Specification 1650X1250X1050MM Trademark HJZ Origin Wuhan, China HS Code 84561000 Production Capacity 20sets/Month

Product Description

Bottle Expire Date CO2 Laser Marking Machine








Our Features:
1.United States imported CO2 laser tube,
2.SINO-GALVO galvo head with speed 7000mm,
3.Imported lens made of zinc selenide,
4.Machine warranty for 2 years,
5.Top quality JCZ motherboard and EZCAD control software,
6.Taiwan MeanWell brand power supply,
7.We support DHL / TNT / FEDEX EXPRESS air shipping to door,

Applicable material:
Wood, paper, leather,cloth, plexiglass, epoxy, acrylic, unsaturated polyester resin and other non-metal materials.

Control software:
-EZCAD software( The latest version of EZCAD)
-Easy to use, smooth operation
-Support WIN XP, WIN7, WIN 8, WIN10 (32bit/64bit)
-Support multiple formats AI, PLT, DXF, BMP, DST, DWG, LAS, JPG, DXP,etc. Techical parameters:

Model	HJZ-CDB-30
Laser source	US SYNRAD
Laser type	Co2 laser
Wavelength	10.6um
Max Single pulse energy	1.0mj
Pulse duration	90-130ns
Laser beam quality M2	<1.2
Marking speed	1-8000mm/s
Frequency	20-60khz
Marking Area	100*100mm-300*300mm (optional)
Marking Depth	0.01-0.08mm
Controller	Computer with marking software
Control program	EZCAD control system  Compatible with win7/8/10
Graphic format supported	JPG,BMP,DXF,PLT,AI,DST
Working voltage	AC220V 50HZ, AC110V 60HZ
Cooling type	Air cooling
Operating parameter	0-40ºC
Warranty	Laser source we warranty for 1 year/the other parts warranty for 2 years
G.W.	90KG
Package(L*W*H)	1090X460X780mm

Packing list:

30W CO2 laser marking machine	1 set
Laser source test report	1 set
CD with EZCAD control program	1 set
Foot switch	1 set
USB flash disk	1 set
Power cord	1 set
Inner hexagon wrench	1 set
Ruler	1 set
