• Model NO.：LS-C
• Transport Package：Plywood Box
• Specification：630mmX590mmX290mm
• Trademark：Lansen
• Origin：Jinan China
• HS Code：8456110090
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. LS-C Transport Package Plywood Box Specification 630mmX590mmX290mm Trademark Lansen Origin Jinan China HS Code 8456110090 Production Capacity 300 Sets/Month

Product Description

High power fast speed Rust Removing Laser machine

Laser cleaning, on the other hand, is non-contact and non-abrasive, and so will only irradiate the material that you want to get rid of. This makes the process in particular, ideal for cleaning intricate and textured materials. You also have a great deal of control over the beam, meaning you can achieve the desired depth that you want to. Further to this, you can irradiate the whole surface layer of a material, or a much thinner layer, say the topcoat of paint, but not the primer below. Or, should you wish, you can just clean a very small section. If using another process which simply blasts the material, it is hard to enjoy such a high level of control. One of the key benefits in the way that laser cleaning works is that not much waste is left over due to the irradiation process; the substrate is simply vaporised rather than left as waste. The majority of the waste that is left over comes as dust particles and can be easily collected and removed by the user.



It is mostly dust particles that are left behind from the laser cleaning process As if all the above isn't
enough, the laser cleaning process is also much faster, leaving staff more able to complete other work and
not spend all of their time cleaning!



Application industry and purpose of Laser Cleaning Machine
Cleaning machine application industry microelectronics: semiconductor components, microelectronics, memory templates, etc.; cultural relic protection: stone carving, bronze, glass, oil painting and murals, etc.; abrasive cleaning: rubber molds, composite molds, metal molds, etc.; surface Treatment: Hydrophilic treatment, treatment of welds before and after welding, etc.; Paint removal and rust removal: aircraft, ships, weaponry, bridges, metal pressure vessels, metal pipes, etc.; aircraft parts, electrical product parts, etc.; Others: urban graffiti, printing rollers, building exterior walls, nuclear industry, Shipbuilding industry, auto parts, rubber molds, high-end machine tools, tire molds Track Environmental protection industry Weapon equipment industry Nuclear power industry and others etc,.



Model	LSF-50/ LSF-100
Laser Power	50W/ 100W
Scan head brand	Sino-Galvo
Cooling way	Air cooling
Laser Wavelength	1064nm
Laser Power	0-100%
Laser Frequency	20-200KHZ
Clean width	1-20mm
Clean length	1mm,3mm,6mm,12mm,25mm,50mm,100mm
Clean speed	1-1000mm/s (adjustable)
Working temprature	0- 40 ºC
Voltage	220V±10%, 50-60hz
LCD control panel size	3.5inch
Operation way	Handhold model
Hand-piece size	406.5×70×113.7mm
Hand-piece weight	2.5±0.1Kg
Optic cable length (bending radius≥250mm)	3m, can be customized
Working Humidity Conditions:	≤ 80%RH
Packing size	630mmX590mmX290mm
Machine size/Gross weight	25kg/35.1kg

Fiber laser rust removal cleaner can do fast cleaning of rust, painting, oil from metal surface, like tinplate heavy rust remove, wire brushed thick rust remove, rusted tool mold cleaning, painting cleaning, etc. It have following features:

1) Non-contact cleaning, without damage to parts matrix.
2) Precise cleaning, with accurate location, precise size and selective cleaning.
3) No chemical cleaning fluid, no consumables, safe and environmental protection.
4) Simple operation, the power can be charged, and the automatic cleaning
can be realized by hand or with the manipulator.
5) Cleaning efficiency is very high and saving time.
6) The laser cleaning system is stable and little maintenance requirement.

About Us

FAQ and CONTACT

Q: If I bought a machine, how could you make it safe while shipping.
A: We have a professtional package suitable for oversea transpotation. Machine will be fixed well in the case.
Q: What's your quality control system?
A: All machines will be tested after finished. We have QC department response for this job. And we already got CE approved.
Q: If I don't know how to use the machine, can you teach me?
A: 1) There is a DVD disc including machine user manual and software user manual c/w machine.
2) Online (skype & phone)
3) Remote desktop software (Teamviewer)
4) Demo Video
