• Model NO.：PEDB-100A
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Power：20W
• Current：AC
• Laser Type：Fiber Laser
• Usage：Metal
• Engraving Machine Type：Fiber Laser Marking Machine
• Gross Weight：28kg
• Working Size：110*110mm
• Carving Line Speed：0-8000 mm,S
• Marking Speed：600-1000 Character , Min
• Minimum Line Width：0.02mm
• Transport Package：Wooden Case with Exporting Standard
• Specification：70*20*50cm
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456100090
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. PEDB-100A Laser Wavelength Fiber Laser Laser Classification Solid Laser Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Laser Power 20W Current AC Laser Type Fiber Laser Usage Metal Engraving Machine Type Fiber Laser Marking Machine Gross Weight 28kg Working Size 110*110mm Carving Line Speed 0-8000 mm/S Marking Speed 600-1000 Character / Min Minimum Line Width 0.02mm Transport Package Wooden Case with Exporting Standard Specification 70*20*50cm Trademark Perfect Laser Origin China HS Code 8456100090 Production Capacity 1000 Sets/ Month

Product Description

Desktop Mini 20W Metal Logo Fiber Laser Marking Machine
(Model:PEDB-100A)

Contact:Crystal

 Product Description of Laser Marking Machine:
The PEDB-100A intelligent mini laser marking machine integrates four core components such as fiber laser, 8mm high-speed galvanometer, power supply and genuine marking system.
This mini laser marking machine realizes the integration of multi-card into one card and card and multi-source power supply into a single source power supply.It is a small-volume, lightweight, fast-speed, high-flexibility, cost-effective mini laser marking machine.




Application of Laser Marking Machine:
1.Applicable materials: this mini laser marking machine is widely suitable for most metal materials, PVC, etc.
2.Applicable industries: the small laser engraving machine is widely applied in hardware products, tool accessories, precision instruments, glasses and watches, jewelry, auto parts, plastic buttons, electronic components, mobile communication, PVC pipe, sanitary ware and other industries.




Product Features of Laser Marking Machine:
1. This mini laser marking machine has beautiful appearance, compact structure and small floor space.
2. The laser light pulse of the small laser engraving machine is narrow, the peak power is high, and the repetition frequency range is wide.
3.This tabletop laser engraving machine has low power consumption and high usability.
4. This mini laser marking machine is easy to operate with high reliability and long service life.
5. There is no consumables or wearing parts of this tabletop laser engraving machine.
6. The small laser engraving machine will not cause shadows and virtual breaks when processing special materials.
7. The column of the mini laser marking machine can be rotated 360° to facilitate multi-angle marking of objects that are not easy to move.





Technical data of Laser Marking Machine:

Model	PEDB-100A Mini Laser Marking Machine
Laser Type	Fiber Laser (Brand:Max)
Laser Power	20w
Laser Wavelength	1064 nm
Beam Quality	M2<1.4
Modulation Frequency	30-60 khz
Carving Line Speed	0-8000 mm/s
Marking Speed	600-1000 Character / min
Focus mode	Manual / Auto
Minimum Line Width	0.02 mm
Minimum Character	0.15 mm
Marking Size	110mm×110mm (Standard) 70mm×70mm (Optional)
Repeatability	±0.002 mm
Cooling Method	Air Cooling
Use environment	Clean or less dust
Working Temperature	10-35 ºC
Machine Power	≤ 160 W
Voltage	AC220V±10%,50 HZ
Working Desk Size	270mm×210mm
Lifting Range	0-300mm
Column Rotation Angle	360°
Light Bridge Displacement Stroke	110mm
Operating Temperature	0ºC-60ºC
Storage Temperature	-40ºC-85ºC
Humidity	5% -95% relative humidity, no condensation

Machine Details of Laser Marking Machine:



After- Sale Service for Laser Marking Machine :
1> All of our machine will be full-checked by our quality control department before the shipment. We make sure that customers will be get good products from us. and all of our machine with a 12 months quality guarantee period.

2> We will supply brochures for simple trouble-shootings of the machine, which will help you dealing with the common problems happened to the machine. We will enclose an "Instruction Book", "Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the customer.

3> We will offer plenty of online supports, just like detailed technical and installation instructions by email, video, telephone and fax.

4> Our engineer can make a door-to-door instruction training service at your local site.




Our Company:
We, Perfect Laser, as a 21 years history industrial equipment manufacture in laser field, 13 year Golden Supplier in Alibaba, with CE/ISO certification, we aims to make high quality products, and also our products have been exported to more than 180 different countries and areas.
