Hand Held Laser Cleaning Machine 1000W 1500W 2000W
Jinan Vmade Cnc Machine Co., Ltd.- After-sales Service：Online Support,Video Technical Support,Free Spare
- Warranty：2 Years
- Application：Biomedicine, Electronic Industry, Automotive Industry, Powder Metallurgy, Manufacturing Industry
- Technical Class：Continuous Wave Laser
- Control：Automatic
- Power Density：Deep Fusion Welding
Base Info
- Laser Classification：Optical Fiber Laser
- Type：Silicon Steel Sheet Laser Welding Machine
- Product Name：Handheld Laser Welding Machine
- Laser Type：Fiber Laser
- Laser Power：1000W ,1500W,2000W,3000W
- Application Material：Metal
- Laser Source：Raycus Brand
- Welding Head：Hanwei Welding Head
- Control System：Hanwei Welding System
- Power Supply：220VAC 10% , 50-60Hz
- Cooling System：Water Cooling
- Transport Package：Strong Water Proof Wood Case
- Specification：1450*780*1350 400KG
- Trademark：Vmade CNC
- Origin：Jinan City of China
- HS Code：8515809090
- Production Capacity：100sets,Month
Description
Product Overview
1)It is easy to operate, can be used by ordinary employees, and the training cost is not high. 2)It has the advantages of high efficiency, large welding size, fast welding speed, fine welding and so on, which reduces the subsequent grinding process. 3)It can be widely used in the welding of stainless steel plate, iron plate, galvanized plate, aluminum plate and other metal materials. 4)The welding point is small, the heat affected area is small, the welding workbench is not needed, and the floor area is small.. 5)As long as equipped with a hand-held laser welding machine, the hand-held laser welding equipment can complete the welding operation, and the replacement cost of accessories is low.
Main advantages of our hand-held welding machine1)Support welding parameter save.
2)CW, Adjust, Argon type, QCW(Pulse welding) Four welding types.
3)Setting wire feeder's digital parameter in monitor.
4)The language include Chinese, English, Korean, Japanese, Russian.
5)The system real-time monitoring condition at operation,Laser source, Water chiller, Control board.
6)Perfect substitute argon welding and electric welding in thin metal material welding area. Like stainless steel, carbon steel, aluminum and etc.HanWei HeadHanwe is one of the only a few supplier around the world, which can research and develop the whole set of hand torch welding machine :Hand torch welding head→Laser control system→Wobble control system→Feeding device. Self-develop the full set and put on themarket. Products with ergonomic concept and design, think through the welding technology applicability and comfort for long-termuse (Weight 0.8 kg). And have the safety lock: Adopt drawer type of protection lens setting for convenience of users themselves for a replacement.
Model Hanwei Series HW-20-60120 Laser power ≤2000W Focal length 150/200 Collimate focus 60/80 Interface type QBH Accessible wave range 1064 Net weight 0.8kg Light source diameter(mm) 1.0,2.0,3.0(Option) Usable laser source All of laser source Control card HZ-039A-10 System M-V6 .02 V6.04 Driver 40*105-DC24V Second Version
1)It is easy to operate, can be used by ordinary employees, and the training cost is not high. 2)It has the advantages of high efficiency, large welding size, fast welding speed, fine welding and so on, which reduces the subsequent grinding process. 3)It can be widely used in the welding of stainless steel plate, iron plate, galvanized plate, aluminum plate and other metal materials. 4)The welding point is small, the heat affected area is small, the welding workbench is not needed, and the floor area is small.. 5)As long as equipped with a hand-held laser welding machine, the hand-held laser welding equipment can complete the welding operation, and the replacement cost of accessories is low.Main advantages of our hand-held welding machine1)Support welding parameter save.
2)CW, Adjust, Argon type, QCW(Pulse welding) Four welding types.
3)Setting wire feeder's digital parameter in monitor.
4)The language include Chinese, English, Korean, Japanese, Russian.
5)The system real-time monitoring condition at operation,Laser source, Water chiller, Control board.
6)Perfect substitute argon welding and electric welding in thin metal material welding area. Like stainless steel, carbon steel, aluminum and etc.HanWei HeadHanwe is one of the only a few supplier around the world, which can research and develop the whole set of hand torch welding machine :Hand torch welding head→Laser control system→Wobble control system→Feeding device. Self-develop the full set and put on themarket. Products with ergonomic concept and design, think through the welding technology applicability and comfort for long-termuse (Weight 0.8 kg). And have the safety lock: Adopt drawer type of protection lens setting for convenience of users themselves for a replacement.
