Automatic Fiber Laser Welding Machine with Raycus Laser Source for Brass and Aluminium
Wuhan TA Laser Machinery Co., Ltd.- After-sales Service：Online ,Door to Door
- Warranty：2 Years
- Application：Automotive Industry, Manufacturing Industry
- Technical Class：Continuous Wave Laser
- Control：Manual
- Power Density：Deep Fusion Welding
Base Info
- Model NO.：TA-FLPW-1000
- Laser Classification：Optical Fiber Laser
- Type：Portable Welding Machine
- Machine Type：Cabinet -- Portable
- Optical Path Transfer：by Fiber
- Power Supply：380V±10%,50Hz
- Laser Type：Fiber Laser Generator
- Wavelength：1070nm
- Laser Power：1000W
- Frequency：5000Hz
- Laser Output Distance：100mm
- Cooling：Water Cooling
- Indicating System：Red Light
- Length of Fiber：5 M
- Gas：Argon Gas
- Transport Package：Wooden Case
- Specification：1000W
- Trademark：TA
- Origin：China
- HS Code：8456110090
- Production Capacity：2000 Sets,Year
Description
Application Industry
Technical Parameter
| Serial Number | Project | Parameter |
| 1 | Laser Generator | IPG1000W/Raycus 1000W |
| 2 | Fiber Length | 20 meters is standard for IPG/Raycus is standard with 10 meters |
| 3 | Laser Welded joint | Hold the Second-Generation Wobble Welding Head |
| 4 | The Cooling Water Tank | Hand-held Laser |
| 5 | The Workbench | No |
| 6 | The Operating System | Touch-Type human computer interaction system |
| 7 | Ailed At Positional | Red Light Positioning |
Product Parameter
| NO. | Project | Parameter |
| 1 | Device Name | Hand-held welding machine |
| 2 | Product Size | 1105 L* 720W* 1005H mm |
| 3 | Laser Provide | 1000W |
| 4 | The Laser Wavelength | 1070nm ± 10nm |
| 5 | Fiber Length | 20 meters is standard for IPG/Raycus is standard with 10 meters 10 meters |
| 6 | Way to work | Continuous/Pulse |
| 7 | Aimed At positioning | Red Light Positioning^ |
| 8 | Welding Thickness Recommendation | Stainless steel/ Carbon steel 0.5-2mm |
| 9 | Welding Clearance Requirements | ≤0.3mm |
| 10 | Working Voltage | Raycus AC380V, IPG AC220V |
| 11 | Shielding Gas | Nitrogen (Purity not less than 99.9%) |
Part of our machine running in the world
We sold more than 2000sets/Yesr in more than 150 countries.All the customer have good feeback for our machine and continue to purchase our machine many times
Our Factory ,Office And Certificaiton
We have 3 factories with more than 32000 square meters .And we have 325 employees working in the head office .All of our machine are pass Euro and USA Standard.
