• Model NO.：PEDB-400H
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Emission Bandwidth (Fwhm)：<10 Nm
• Long-Term Average Power Instability：<5%
• Pulse Width(Fwhm)：100 Ns
• Laser Switching on Time：180 μsec
• Laser Switching off Time：180 μsec
• Pulse Repetition Rate* kHz：20-80 kHz
• Energy Per Pulse (Prr = 20 kHz)：0.95 Mj
• Typical Beam Quality, M2：<1.8
• Output Fiber Delivery Length：3m
• Operating Voltage：220V
• Transport Package：Wood Crafcase
• Specification：60kg
• Trademark：Perfect Laser
• Origin：Hubei
• HS Code：84561000
• Production Capacity：1000 Units Per Month

Laser system

Scanning Speed:

0-7000mm/s

Marking Speed:

0-5000mm/s

Marking size:

110mm×110mm (F-theta 160)

Spot size:

≤ 40 micron (F-theta 160)

Cooling unit:

Air cooled

Pilot laser:

650nm diode laser,visible red light for marking guide

Continuous working time:

≥16h

Humidity:

45~85% (no condensation)

Operating temperature:

0~40ºC

Detailed Images:





Company Information:
Perfect laser Co. Ltd. (China) was founded in 1995, located in the core area of "China Optic Valley" - Wuhan city. Occupied with 3000 m2 ground, including R&D building and production area. It has more than 180 employees, most of them are with a bachelor degree or even a doctorate degree. Executed by reliable quality and reasonable price, our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries such as the USA, Italy, Korea, Singapore, Poland, Turkey, Sweden, Saudi Arabia to worldwide.

FAQ

Q1.: What's the package?
A: We have 3 layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.

Q2.: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe transportation. We have exported to 180 countries worldwide. So please don't worry, you will receive the parcel in good condition.

Q3.: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.

Q4.: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
