RF Mini CO2 Nonmetal Laser Cutting Engraving Marking Machine
Jinan Lansen Laser Equipment Co., Ltd.- Laser Visibility：Invisible
- Applicable Material：Nonmetal
- Cooling System：Air Cooling
- Technical Class：Continuous Wave Laser
- Laser Wavelength：CO2 Laser
- Laser Classification：Solid Laser
Base Info
- Model NO.：LSF30W
- Type：CO2 Laser Marking Machine
- Marking Method：Scanning Marking
- Laser Type：Davi RF CO2 Laser
- Comtrol System：Jcz
- Operation System：Microsoft Windows 7. 8. 10 System
- Power Supply：220V,60Hz,8A(110V,60Hz,15A Can Choose)
- Transport Package：Wood Boxes
- Specification：1180*630*520mm
- Trademark：Lansen
- Origin：China
- HS Code：8456110090
Description
Basic Info.
Model NO. LSF30W Type CO2 Laser Marking Machine Marking Method Scanning Marking Laser Type Davi RF CO2 Laser Comtrol System Jcz Operation System Microsoft Windows 7. 8. 10 System Power Supply 220V/60Hz/8A(110V/60Hz/15A Can Choose) Transport Package Wood Boxes Specification 1180*630*520mm Trademark Lansen Origin China HS Code 8456110090Product Description
RF Mini Co2 Nonmetal Laser Cutting Engraving marking machine ls
Parameters:| Model | co2 mini Laser Marking machine |
| Laser type | Co2 Laser |
| Laser power | 20w/30w |
| Laser Wavelength | 10 . 6μm |
| Laser Repetition Frequency | ≤25KHZ |
| Marking Area | 100mm*100mm / 200mm*200mm |
| Marking Deep | ≤0 . 3mm |
| Linear Speed | ≤7000mm / s |
| Min.Line Width | 0 . 1mm |
| Repeatable Accuracy | ±0.01mm |
| Min.Letter | 0 . 4mm |
| Gross Power | 0.8-1 5KW |
| Power Requirement | 220V / 50HZ |
| Cooling system | Air Cooling |
| Warranty | Two years |
Co2 laser marking machine adopts imported CO2 RF laser generator and high speed galvo scanner system. With high quality optic devices, high stability laser generator, full automatic control system. The machine system working with high precision and fast speed, very stable performance, can work continuously for a long time and can be applied directly in large quantities of online processing lines.
1. General machine, adopted back focalization, laser power is controlled by the software and serially adjustable. It is applicable to fine marking on nonmetal materials with low requirements.
2. Adopting CO2 RF laser tube which has excellent performance and long life<20k hours.
3. Adopting high-speed galvanometer system with high speed, high precision and stable performance.
4. Adopting imported optics lens, low loss, excellent focalization performance.
5. The marking software is mightiness ,under WINDOWS interface, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP etc. a variety of software output files. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font. Support automated coding, serial number, batch number, date, bar code and two-dimensional code marking.
Machine details:
Applications:
Aplicable Industries:
Wide used in all kinds of cosumer goods, food packing, fodder packing, pharmaceutical packing, architectural ceramics, clothing accessories, leather,fabric cutting, craft gift, rubber products, shell palte, jeans cloth, furniture, etc.
Applicable Materials:
RF Laser Marking machinemainly used for marking on nonmetal material, it can marking on mobile phones buttons, plastic translucent keys, electronic components, integrated circuits(IC), electrical appliances, communication products, sanity ware, tools, accessories, medical device industry, jewelry, glass and clocks, auto parts, luggage buckle, cooking utensils, cut paper and other industries, etc.
