• Model NO.：MT-F20
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Laser Marking
• Wavelength：1064nm
• Frequency Range：20-200kHz
• Beam Quality：<1.6m2
• Marking Speed：<8000mm,S
• Marking Depth：≤2mm
• Transport Package：Standard Export Wooden Box
• Trademark：Mactron
• Origin：Guangdong, China
• Production Capacity：200

Basic Info.

Model NO. MT-F20 Type Optical Fiber Laser Marking Machine Marking Method Laser Marking Wavelength 1064nm Frequency Range 20-200kHz Beam Quality <1.6m2 Marking Speed <8000mm/S Marking Depth ≤2mm Transport Package Standard Export Wooden Box Trademark Mactron Origin Guangdong, China Production Capacity 200

Product Description

Production Description
20W Fiber Laser Marking Machine adopts the imported fiber laser generator, high speed Galvo system to enable stable laser output and high qulity laser mode. This model 20W Fiber Laser Marking boasts for its fast marking speed, good marking effect and high efficiency to meet the demand of mass production. FurthermoreFiber Laser Marking Machine Price also enjoys the advantages of easy operation, low running cost, long-term trouble -free working and free from maintenance. All these factors devotes to its capacity to satisfy industrial production.



Model	MT-F20
Peak Laser Power	20W
Wavelength	1064nm
Processing Area	70*70MM/110*110MM/175*175MM/300*300MM(Optional)
Frequency Range	20-200Khz
Beam Quality	<1.6M2
Laser Source Lifetime	100000h
Marking Speed	<8000MM/S
Marking Depth	≤2MM
Repetition Precision	0.01MM
Min.Line Width	0.01MM
Min.Character	0.2MM
Cooling Mode	Air Cooling
Lifting Height	100-500MM(700MM)Optional
Graphic Formats Supported	PLT,DST,AI,DXF,BMP,JPG,CAD,CDR,DWG
Operating temperature	10ºC-40ºC
Warranty	1 Year
Humidity	5% to 85% (Free of Condensed Water )
Gross Power	<500W
Power source	AC110V/220V± 10%, 50/60HZ



Feature:

1. One-unit structure with manually focusing system and user-friendly operation.
2. Imported isolator for protection of the fiber laser generator to increase the stability and prolong the laser life.
3. Laser beam quality is much better than the traditional laser marking machine. Fiber laser beam mode is TEM00; focus diameter is less than 20um; expanding angle is only 1/4 of the YAG-DP. Therefore it is esp. good at delicate marking.
4. High electricity-laser exchange ratio, gross electricity consumption is less than 500W, which is 1/10 of the YAG's consumption .
5. Free from maintenance, long working life, small size, suitable for any working environment .
6. Fast marking speed, 2-3 times faster than the traditional marking machine .
7. The Fiber Laser Marking software supports files such as CorelDraw, AutoCAD, Photoshop and PLT,PCX,DXF,
BMP; SHX OR TTF can be directly adopted; the functions such as auto coding for sequence No., group mark, date, barcode and so on.



Applicable Industry:

This 20W Fiber Laser Marking Machine widely used in mobile button, plastic transparent button, electronic parts, IC, tools, communication products, bathing products, tool accessories, glasses and watches, jewelry, button decoration for boxes and bags, cookers, stainless steel products and so on.

Production Flow

Samples



FAQ

1. Q: Are you a factory or a trading company?
A: We are factory manufacturing packaging machines and we provide perfect OEM and after-sale service.

2. Q: How can you guarantee that I have a good sale on this product?
A: We offer professional technology and after-sale service.

3. Q: How can I know your machine is designed for my product?
A: You can send us samples of your product and we test it on machine.

4. Q: How can I get the sample to check the quality?
A: If you want to check the quality, pls kindly send us the sample for testing.

5. Q: How long can I expect to get the sample?
A: We ensure that the samples could be done within 1-2 days once we receive the sample from your side.

6. Q: How can I pay my order?
A: We accept T/T, Western Union ,Money Gram paying methods.

7. Q.If we do not know how to use the machine,can you teach us?
A: Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy, we will have our professional engineer to your country,you only need pay for some fee,like tickets, hotel and meal.
