CO2 Laser Cutting Machine 80W 100W 130W CNC Laser Engraving Machine
Redsail Technology Co., Ltd.- After-sales Service：Lifetime Service
- Warranty：12 Month
- Application：Leather Industry, Domestic, Printing & Packaging, Crafts Industr, Advertising Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Automatic Grade：Automatic
Base Info
- Model NO.：R6090
- Applicable Material：Nonmetal
- Type：Flat-Plate
- Laser Classification：Gaseous Laser
- Engraving Method：Vector Engraving
- Working Size：900mm*600mm
- Laser Power：Reci 80W 100W 130W
- Adjust Table：Electronic up Down 180mm
- Working Table：Blade Platform
- Driver：Stepper Motor
- Engraving Speed：0-1000mm,S
- Max Speed：800mm,S
- Color：Blue,White
- CNC or Not：Yes
- Graphic Format：Ai, BMP, Dxf, Dxp, Plt
- Controller System：Ruida
- Control System：DSP
- Warning Light：Yes
- Rotary Attachment：Optional
- Red-DOT：Yes
- Transport Package：1920mm*1540mm*1450mm
- Specification：4.32 Cu. m
- Trademark：REDSAIL
- Origin：China
- HS Code：8456110090
- Production Capacity：2000 Units,Year
Description
Detailed Photos
Packaging & Shipping
FAQ
Q: Do I need two laser machines to engrave and cut separately?
A: No, the laser machines we provide are capable of both engraving and cutting. One machine alone can fulfill the two purposes.
Q: Do the laser machines need to be connected to a laptop or desktop computer to work?
A: Yes, either is ok. It supports Windows 10, Windows 2000, Windows XP, Win 7, and other operating systems
Q: What kind of graphic format does it support?
A: JPG, PNG, BMP, PLT, DST, DXF, CDR, AI, DSB, GIF, MNG, TIF, TGA, PCX, JP2, JPC, PGX, RAS, PNM, SKA, RAW , etc.
Q: How to distinguish laser tubes with different powers and applications?
A: 1. Laser tube length (relatively speaking, the longer, the bigger)
2. Laser tube diameter (relatively speaking, the thicker, the bigger)
3. The bigger a laser tube power is, the deeper the machine can cut, but its light spot is bigger. So, it is better to use a machine with a low-power laser tube to engrave, such as 40W, 50W or 60W.
Q: Is it better to increase blow to improve laser processing performance?
A: For some thick materials, it works. But, when carving some other materials, you need to blow less.
Q: How long will it take to learn to operate a laser machine?
A: If you are able to use some basic graphic design software, it will only take a few hours to master the operation. You just need to do some simple tests on different processing materials to know how to set the correct speed and laser power.
Q: Is a laser machine in operation harmful to our bodies?
A: It is not harmful as long as the laser is not exposed directly to skin and eyes.
Sample display
Certificate
