• Model NO.：laser welder 1000w
• Type：Automatic Laser Welding Machine
• Name：Laser Welder
• Laser Source：Raycus
• Laser Power：1000W 1500W 2000W
• Material：Metal
• Laser Wavelength：1070nm
• Laser Welding Depth：Max 4mm
• Laser Welding Frequency：≤100Hz
• Adjusting Range of Light Spot：0.1-3.0mm
• Integrity Power：Max 8kw
• Power Supply：3phase 380V
• Sighting Positioning System：Automatic Wire Feeding Machine
• Cooling：Water Cooling
• Optical Fiber Line Length：5m
• Master Unit Dimensions：1440*840*1360mm
• Transport Package：Plywood Case Packaging
• Specification：1440*840*1360mm
• Trademark：Baokun Brand
• Origin：Weifang, Shandong, China
• HS Code：8456110090
• Production Capacity：200sets,Month

Basic Info.

Model NO. laser welder 1000w Type Automatic Laser Welding Machine Name Laser Welder Laser Source Raycus Laser Power 1000W 1500W 2000W Material Metal Laser Wavelength 1070nm Laser Welding Depth Max 4mm Laser Welding Frequency ≤100Hz Adjusting Range of Light Spot 0.1-3.0mm Integrity Power Max 8kw Power Supply 3phase 380V Sighting Positioning System Automatic Wire Feeding Machine Cooling Water Cooling Optical Fiber Line Length 5m Master Unit Dimensions 1440*840*1360mm Transport Package Plywood Case Packaging Specification 1440*840*1360mm Trademark Baokun Brand Origin Weifang, Shandong, China HS Code 8456110090 Production Capacity 200sets/Month

Product Description

                          Free shipping high performance laser welder with chep price
Laser welder consists of the latest generation of fiber laser generator, wobble welding head and cabinet.

1.With simple operation, beautiful and smooth weld seam effect, fast welding speed and no consumables needed during welding process.

2. Welding in thin metal plates such as stainless steel plates, iron plates and galvanized plates can perfectly replace traditional argon arc welding and electric welding.

3.Fast welding speed, 2-10 times faster than traditional welding.One unit of laser welding machine can replace at least two workers yearly

Name	portable laser welder
Maximum laser power	1000/1500w
Laser wavelength	1070nm
Laser welding depth	≤4mm
Pulse width	≤20ms
Laser welding frequency	≤100Hz
Adjusting range of light spot	0.1-3.0mm
Size of light spot	0.2-3.0mm
Integrity power	≤8KW
Power supply	380V/3-phase/50Hz/60A 220V/Single phase/50Hz
Maximum bearing of standard work bench	≤100kg
Optical fiber line length	5m
Repeating precision of work bench	±0.01mm
Positioning precision of work bench	±0.02mm
Sighting positioning system	automatic wire feeding machine
Cooling method	Water cooling
Master unit dimensions	1440*840*1360mm

Different welding of non-standard metal parts, manual welding is more flexible;

Perfect welding quality, small deformation, high penetration depth, no weld penetration;

A variety of welding processes, spot welding, seam welding, welding, etc.;

High welding efficiency, replacing traditional TIG welding equipment;

The largest welding benefit cost, no consumables energy saving and environmental protection

Q1:How do I choose the right laser welder for me?
A:You can tell us the maximum working area, material and thickness you want to cut, and we can help choose the most suitable machine.

Q2:When I got this machine, but I don't know how to use it. What should I do?
A:You can come to our factory to study, we provide free study, and we will also provide videos and English manuals randomly. If you still have questions,you can contact us through skpe, WeChat or email.

Q3: If some problems happen to this machine during warranty period, what should I do?
A:We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.

Q4: what payment for this machine?
   A: 30%TT advance , after finished the production, we will send you the test video and machine pictures for you check, only satisfied with the machine, then you can pay the 70% balance payment.
