Portable Fiber Laser Rust Removal Machine for Cleaning Rusty Metal
Henan Wadley CNC Machinery Co., Ltd.- After-sales Service：Online Support, Free Spare Parts
- Power：200w, 200W, 500W, 1000W
- Control Type：Automatic
- Warranty：1 Year
- Applicable Material：Stainless Steel, Carbon Steel,
- Weight：140 Kg
Base Info
- Model NO.：Laser Rust Removal Machine
- Handheld Cleaning：1000-8000mm,S
- Motion Type：Handheld
- Cooling Type：Water Cooling
- Scanning Width：10-100mm
- Transport Package：Wooden Case
- Specification：850mm*700mm*880mm
- Trademark：wadley
- Origin：China
- Production Capacity：50sets , Month
Description
DIHORSE 200W fiber lser cleaning machineModel DH-CL200 Laser Raycus RFL-P200 Power 200w Laser gun weight <3kg Set the environment Flat, no vibration, no impact Operation Mode Pulsed Polarization State Random Nominal average output power 200≤P≤210W Output Power Tunability 10-100% Center wavelength 1064±5nm Spectral width ≤10nm Output Power Instability ≤5% Pulse duration 90-130ns Pulse setup time <200us Pulse off time <100us Pulse repetition rate 10-50kHz Beam diameter 3-5mm Delivery Cable Length 5m Power Supply AC 220V±10% , 50/60Hz, Single-phase Operating Temperature 10~40ºC Humidity ≤70% Cooling Method Water Cooling Water chiller S&A CW-5200 Move way Ha nd pushing Scanning width 10-80mm Machine weight 180kg Machine package dimension 122*81*138kg
Advantate:
1. It can easily solve the environmental pollution caused by chemical cleaning without using any chemicals and cleaning liquid.
2. Laser cleaning has no mechanical force on the surface of the object to be cleaned and will not damage the surface of the object to be cleaned. The cleaning media does not adhere to the surface of the object to be cleaned and there is no secondary contamination.
3. The laser can be transmitted through optical fiber, which is easy to operate at a long distance. It can clean parts that are difficult to reach by traditional methods and can be used in some dangerous places to ensure personnel safety.
4. Laser cleaning can remove various contaminants on the surface of various materials to achieve the cleanliness that cannot be achieved by traditional cleaning.
5. The cleaning system can be used stably for a long time, with high cleaning efficiency and low operating cost.
Cleaning head weight
The cleaning head refers to the tip of the fiber length; where the laser pulse shoots out from. Weighing at 4.4 pounds, the DIHORSE 50W laser cleaning machine is light enough to be handheld for prolonged periods.
Scanning Width
The laser beam has an adjustable scanning width, ranging between 10mm and 80mm. You are at liberty to adjust this width to your preference, depending on the surface material in question.
Focus spot diameter
The laser beam from the DIHORSE 50W laser cleaning machine comes with a focus spot diameter of 0.08mm, which allows you to focus the pulse to the very hard-to-reach spots.
Power adjustment range
A good laser cleaning machine will allow you to adjust the power range depending on how tough a stain is to remove. The Raycus 50W offers precisely that, with a power adjustment range of 10% to 100%.
Advantate:
1. It can easily solve the environmental pollution caused by chemical cleaning without using any chemicals and cleaning liquid.
2. Laser cleaning has no mechanical force on the surface of the object to be cleaned and will not damage the surface of the object to be cleaned. The cleaning media does not adhere to the surface of the object to be cleaned and there is no secondary contamination.
3. The laser can be transmitted through optical fiber, which is easy to operate at a long distance. It can clean parts that are difficult to reach by traditional methods and can be used in some dangerous places to ensure personnel safety.
4. Laser cleaning can remove various contaminants on the surface of various materials to achieve the cleanliness that cannot be achieved by traditional cleaning.
5. The cleaning system can be used stably for a long time, with high cleaning efficiency and low operating cost.
Cleaning head weight
The cleaning head refers to the tip of the fiber length; where the laser pulse shoots out from. Weighing at 4.4 pounds, the DIHORSE 50W laser cleaning machine is light enough to be handheld for prolonged periods.
Scanning Width
The laser beam has an adjustable scanning width, ranging between 10mm and 80mm. You are at liberty to adjust this width to your preference, depending on the surface material in question.
Focus spot diameter
The laser beam from the DIHORSE 50W laser cleaning machine comes with a focus spot diameter of 0.08mm, which allows you to focus the pulse to the very hard-to-reach spots.
Power adjustment range
A good laser cleaning machine will allow you to adjust the power range depending on how tough a stain is to remove. The Raycus 50W offers precisely that, with a power adjustment range of 10% to 100%.
