Small Scale 600W YAG Laser Cutting Machine (DW-YAG-0505)

Jinan Dwin Technology Co., Ltd.
  • Application:Home Appliance
  • Cooling System:Air Cooling
  • Technical Class:Continuous Wave Laser
  • Applicable Material:Nonmetal
  • Structure Type:Desktop
  • Laser Classification:Free Electron Laser

Base Info

  • Model NO.:DW-YAG-0505
  • Laser Technology:Laser Control Fault Cutting
  • Usage:Metal
  • Drive Type:Stepper Drive
  • Certification:CE, FDA
  • Laser Type:YAG
  • Control:Automatic
  • Current:AC
  • Condition:New
  • Engraving Machine Type:YAG Laser Cutting Machine
  • Power:600W
  • Transport Package:Plywood Box, Free of Fumigation
  • Specification:CE, FDA
  • Trademark:DWIN
  • Origin:Jinan City, Shandong Province
  • HS Code:8456100090
  • Production Capacity:50 Sets,Month

Description

Basic Info.

Model NO. DW-YAG-0505 Laser Technology Laser Control Fault Cutting Usage Metal Drive Type Stepper Drive Certification CE, FDA Laser Type YAG Control Automatic Current AC Condition New Engraving Machine Type YAG Laser Cutting Machine Power 600W Transport Package Plywood Box, Free of Fumigation Specification CE, FDA Trademark DWIN Origin Jinan City, Shandong Province HS Code 8456100090 Production Capacity 50 Sets/Month

Product Description

                   small scale 600w YAG laser cutting machine (DW-YAG-0505)

Features:

(1
) Cutting surface is smooth and less dross. The maximum thickness is up to 10mm (cutting carbon steel). This is the maximum cutting thickness in small and medium power YAG cutting industry.

(2) Stainless steel below 4mm and mild steel below 8mm can just use air to laser cut (no required oxygen gas Good cutting effect, maximizing reducing use-cost.

(3) Metal parts of different shapes can be auto arranged in an optimal way. Excess material nesting function enable excess material reuse. Material saving up to 8%-10% than general processing

(4) Dynamic focusing system. When cutting different thickness metal sheets and uneven materials, adjusting focus is no required, so as to achieve fast cutting and greatly improve working efficiency.


Application:

YAG Laser cutting machine has been widely used in manufacturing billboard ,sheet metal structure, high -low voltage electric cabinet, textile machinery, kitchenware , saw bits ,precision metal parts ,metal artware.

Applicable materials:

Stainless steel ,mild steel/carbon steel ,Copper, aluminum, alloy steel ,spring steel ,galvanized  plate ,aluminum coated plate  and some other alloy plate and pipe including titanium alloy etc

Technical Parameter:

ModelDW-YAG-0505DW-YAG-0404DW-YAG-0303
Working area500*500mm400*400mm300*300mm
Max output power600W600W600W
Max Cutting  thickness10mm( carbon steel)10mm( carbon steel)10mm( carbon steel)
Laser wavelength1064nm1064nm1064nm
Pulse frequency1-300HZ1-300HZ1-300HZ
Max Cutting speed35mm/s35mm/s35mm/s
X Y Z Positioning accuracy / X Y Z <+-0.08mm<+-0.08mm<+-0.08mm
X Y Z re-orientation accuracy /X Y Z<=+-0.04mm<=+-0.04mm<=+-0.04mm
Machine weight1400KG1400KG1400KG
Cooling modelWater coolingWater coolingWater cooling
Power Supply380V/50HZ380V/50HZ380V/50HZ

Samples:
Small Scale 600W YAG Laser Cutting Machine (DW-YAG-0505)

 Packaging:
Small Scale 600W YAG Laser Cutting Machine (DW-YAG-0505)

Our Servies:

1. The machine guarantee is 12 months.

2. 24 hours technical support by email or calling.

3.  Friendly English verson manual and operation video CD disc.


Certificate:
