Portable Fiber Laser Marking Machine Metal Stainless Steel Aluminum Silver Gold Ring Jewelry Engraver
Wuhan HJZ Laser Technology Co., Ltd.- After-sales Service：Provided
- Warranty：3 Years
- Laser Visibility：Visible
- Applicable Material：Nonmetal
- Cooling System：Air Cooling
- Technical Class：Pulse Laser
Base Info
- Model NO.：HJZ-DB-01
- Laser Wavelength：Fiber Laser
- Laser Classification：Fiber Laser
- Type：Optical Fiber Laser Marking Machine
- Marking Method：Scanning Marking
- Laser Output Power：20W, 30W, 50W
- Engraving Speed：9000mm,S
- Operating Voltage：110-240V
- Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf, Dxp
- Marking Area：110*110mm, 175*175mm, 220*220mm, 300*300mm
- Certification：CE.FDA
- Condition：New
- Application Material：0.1-2mm
- Process Material：Metal and Some Non-Metal
- Delivery Time：1-3days
- Laser Source：Raycus
- Lifespan：Over 20, 000hours
- Control Software：Ezcad Software
- Name：30W Nonmetal Engraving Machine
- Transport Package：Standard Plywood Packing for Export
- Specification：1650X1250X1050MM
- Trademark：HJZ
- Origin：Wuhan, China
- HS Code：84561000
- Production Capacity：600sets,Month
Description
Technical parameter
Item / Model
HJZ -DB-04 (20/30/50/60/70/100W)
Laser source
Domestic Raycus(Germany IPG/China Raycus/MAX/JPT Mopa color marking for optional)
Laser power
20w, 30w, 50w,60w ,70w,100w
Laser type
Fiber laser
Graphic Format Supported
PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO,
DXF
Marking speed
≤9000mm/S
Max.Marking Depth
≤0.4mm
Laser Wavelength
1064nm
Marking lines
1-10 marking lines(in the marking area)
Minimum line width
0.01mm
Minimum character
0.15mm
Resolution ratio
0.01mm
Graphic format supported
BMP, PLT, DST, DXF, AI
Software supported
TAJIMA, CorelDraw, Photoshop, AutoCAD
Equipment Dimensions
420*320*800mm
Net Weight:
150kg
(different model has different weight,detailed can be confirmed with sellers)
Unit Power
≤500W
Optional Spare Parts
Rotary/Protection glasses/outside red light/night light and so on.
