Focuslaser Jewelry Laser Welding Machine

Guangzhou Focuslaser Co., Ltd.
  • Laser Visibility：Invisible
  • Applicable Material：Metal
  • Cooling System：Air Cooling
  • Technical Class：Continuous Wave Laser
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Semiconductor Laser

Base Info

  • Model NO.：FL-70PW
  • Type：Optical Fiber Laser Marking Machine
  • Marking Method：Scanning Marking
  • Model：Laser Marking Machine
  • Transport Package：Export Box
  • Specification：450x300x350mm
  • Trademark：FOCUSLASER
  • Origin：China
  • HS Code：84561000
  • Production Capacity：2000 Set,Year

Description

Basic Info.

Model NO. FL-70PW Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Model Laser Marking Machine Transport Package Export Box Specification 450x300x350mm Trademark FOCUSLASER Origin China HS Code 84561000 Production Capacity 2000 Set/Year

Product Description

Parameters
Input VoltageAC220V±10% 50Hz
Laser Frequency1.0~10.0Hz Continuously Adjustable
Pulse Width0.1~10.0ms Grading Adjustable
Spot Diameter Adjusting Scope±3.0mm
Laser Output Power≤65W
Aiming and PositioningCCD and Microscope
Environmental Temperature≤45ºC
Operating ModeTouch Control
Laser Wavelength1064nm
Display touch screen mounting dimensions137*190(mm)
Machine DimensionsL 510*W 295*H 395(mm)


Focuslaser Jewelry Laser Welding Machine
Focuslaser Jewelry Laser Welding Machine
Focuslaser Jewelry Laser Welding Machine
Focuslaser Jewelry Welding laser machine Jewelry welding spot welding machine welding tools


Thank you for choosing the FOCUSLASER portable Jewelry laser welding machine, which will provide you with excellent performance, High quality, efficient welding service. It is easy to operate.

In order to get the best results from your machine, please read these operating instructions carefully before use.
Equipment use precautions:
1. The machine working voltage is AC220V/50Hz and capacity 10A.
2. Since the main components of the machine are optical components, in order to keep them clean, it should be ensured the installation room is dry and clean, free from dust or less dust, preferably in an air-conditioned environment.
3. There is a high voltage inside the machine. Do not open the power supply chassis without authorization to prevent electric shock.
4. Ensure that the equipment casing is safely grounded.
5. Please ensure that the water tank is full of water before starting the machine, and regularly change purified water tanks every month to ensure the water tank clean.
