Powerful 2000W Continuous Fiber Laser Cleaning Machine for Metal Rust/Greasy Dirt/Oxidation of Paint

Jinan Upgoal Mechanical Equipment Co., Ltd.

Warranty：1-2 Years
Laser Power：2000W Fiber Laser, Raycus Brand

Base Info

Model NO.：UG-2000LC
Laser Wave Length：1070 Nm
Fiber Length：Standard10m Maximum 15m
Pulse Width：0.1-20ms
Gas Source：Argon or Nitrogen
Working Mode：Continuous or Modulate
Cooling System：Water Cooling, Industrial Water Chiller
Welding Speed Range：0~120 mm,S
Welding Thickness Recommendations：0.5-4mm
Scan Length：150mm
Laser Head：Single Wobble Handheld Laser Head( Relfar)
Controller：Touch Screen Laser Cleaning System( Relfar)
Working Voltage：AC380V, 50,60Hz, Three Phases
Transport Package：Plywood Case
Specification：1650*720*1450mm, 341KGS
Trademark：UPGOAL
Origin：China
HS Code：8515809090
Production Capacity：300set Per Month
Package size per unit product：133.00cm * 72.00cm * 145.00cm
Gross weight per unit product：314.000kg

Description

Powerful 2000W Continuous Fiber Laser Cleaning Machine for Metal Rust/Greasy Dirt/Oxidation of Paint

Applications & Features

Professional touch screen laser cleaning system( RelFar brand) with large 150mm scanning width( can be customized into 200mm) : it has variety of fiber interface and can be adapted to various lasers; fast and simple replacement of protective lenses; with the optimized optical design, built-in water cooling can work steadily for a long time under high power.
Powerful 2000W Continuous Fiber Laser Cleaning Machine for Metal Rust/Greasy Dirt/Oxidation of Paint

Industrial Water chiller( Teyu S&A RMFL-2000): One of the biggest convenience of the machine is the inside water chiller. It saves a lot of the machine's dimension.It is constant temperature industrial type.

Connect with the Argon gas or Nitrogen gas before cleaning

Fiber laser cable & power cable
Powerful 2000W Continuous Fiber Laser Cleaning Machine for Metal Rust/Greasy Dirt/Oxidation of Paint

Technical Parameters

Laser Power	2000W(Raycus,RFL-C2000 model)
Laser Wave Length	1070 NM±20nm
Laser Source	2000W(Raycus,RFL-C2000 model)
Fiber interface	QBH
Fiber Length	Standard10M, maximum 15M
Laser Pulse frequency	1-20HZ
Pulse Width	0.1-20ms
Cleaning head	Portable single wobble handheld cleaning head (RelFar brand, 0.83kg)
Cleaning system	RelFar brand, ,7"display screen and V2 mother board
Scanning width	0-150mm
Scanning speed	20000mm/s
Collimation focal length	50mm
Focus length	600mm
Focus adjustment range	-10mm~+10mm
Clear aperture	Φ25
Gas source	Argon or Nitrogen ≥0.5~0.8Mpa
Working mode	Continuous or modulate
Beam quality	M2<1.2
Line width	<5nm
Straight modulate	0-5KHZ
Cooling system	Water cooling, industrial water chiller,Teyu S& A brand, RMFL-2000
Working environment temperature	15~35 ºC
Humidity range of working environment	< 70%No condensation
Working Voltage	AC380V, 50/60Hz, three phases for 2000W
Total power	about 10,000W

Reference Welding Cleaning Sample Photos
Powerful 2000W Continuous Fiber Laser Cleaning Machine for Metal Rust/Greasy Dirt/Oxidation of Paint
Accessories & packing

Working videos:

https://youtu.be/VMCy-2skEAc

For more information, just feel free to contact us!
