• Model NO.：HSGP-3KC
• Laser Classification：Semiconductor Laser
• Engraving Method：Lattice Engraving
• Engraving Machine Type：Laser Engraving Machine
• Current：AC
• Laser Type：Semiconductor
• Usage：Glass
• Laser Pumping：Semiconductor Diode
• Machine Size：104*78*125cm After Packing
• Transport Package：Flight Box
• Specification：CE SGS FCC FDA
• Trademark：holylaser
• Origin：Yiwu, Zhejiang Province
• HS Code：8456110090
• Production Capacity：50per Month

 Type

HSGP-5KB

HSGP-4KB

HSGP-3KC

HSGP-3KD

Laser wavelength

532nm

Laser frequency

5KHZ(5000HZ)

4KHZ(4000HZ)

3KHZ(3000HZ)

3KHZ(3000HZ)

Max.pulse energy

1.2mj

Laser power

3w

Pulse width

7ns

Beam quality

M2<1.5

Max.engraving speed point

≤300000dots/min

≤240000dots/min

≤180000dots/min

≤180000dots/min

Max.marking scope

300*400*130mm

300*400*130mm

300*400*130mm

150*200*80mm

Laser head

one

Resolution

800DPI-1200DPI

Focal length

≥100mm

Focus diameter

0.02mm

Cooling

Air cooling

Application materials

Crystal Glass Etc

Device input power

AC220V±10%50-60HZ

Product feature:
 1.This machine can engrave on both 2D and 3D, (depends on your design).
 2.Fast speed: only about 2 minutes can engrave a 50*50*80mm size crystal.
 3.Good quality guaranty:
 Laser source parts imported from Germany,
 Laser Q switch imported from England,
 Laser transport cable wire imported from France.
 4. Strong team: Even our Engineers can speak English, strong support for service and training to customers.
 5. Free maintenance.

Supported by the Yiwu City Government
Copperate with the Zhejiang University, update for technology
We are the manufacturer, our price are more competitive.
