Low Price 1000W 1500W 2000W Raycus Laser Source Handheld Laser Welding Machine
Ningbo Zhen Yue Machinery Co., Ltd.- After-sales Service：Online Sales After Service
- Warranty：2 Years
- Application：Electronic Industry, Automotive Industry, Manufacturing Industry, Aviation,Chemical Industry
- Technical Class：Pulse Laser
- Control：Manual
- Power Density：Deep Fusion Welding
Base Info
- Model NO.：HR-SCW1500
- Laser Classification：Optical Fiber Laser
- Type：Portable Welding Machine
- Weight：150kg
- Dimension：1100X620X1100mm
- Power Demand：220V,50Hz
- Laser Device：Raycus
- Transport Package：Standard Export Plywood Cases
- Specification：1100x620x1100mm
- Trademark：HAIRONG
- Origin：China
- HS Code：8515809090
- Production Capacity：300units,Month
Description
Laser Power
1000W
1500W
2000W
Maximum Input Power
14 KW
14 KW
14 KW
Laser Medium Nd
Optical Fiber
Optical Fiber
Optical Fiber
Laser Wavelength
1064 nm
1064 nm
1064 nm
Rated laser output power
300~1000 W
300~1000 W
300~1000 W
Laser power instability
≤ ±2.5%
≤ ±2.5%
≤ ±2.5%
Spot Diameter
0.3 mm - 0.8 mm
0.3 mm - 0.8 mm
0.3 mm - 0.8 mm
Pulse Width
0.2 ms - 20 ms
0.2 ms - 20 ms
0.2 ms - 20 ms
Pulse Frequency
1 Hz - 150 Hz
1 Hz - 150 Hz
1 Hz - 150 Hz
Welding Depth
1mm
2mm
3mm
Positioning Accuracy
0.02 mm
0.02 mm
0.02 mm
Repeat positioning accuracy
±0.01mm
±0.01mm
±0.01mm
Cooling
Circulating Water Cooling
Circulating Water Cooling
Circulating Water Cooling
Power Demand
220V/50HZ
220V/50HZ
220V/50HZ
Dimension
1100x620x1100mm
1100x620x1100mm
1100x620x1100mm
Weight
150kg
150kg
150kg
3.Product Superiority
1). Stable laser energy and good beam mode.
2). It has high aspect ratio, small weld width, small heat affected zone, small deformation and fast welding speed.
3). It is combined with computer technology and uses CNC automatic operation.
4). It is of high precision, high efficiency, low processing noise and has no pollution to the environment.
5). It has the function of automatic protection by current interruption in the case of misoperation and over temperature.
4.Application Fields
It is applicable to welding gold, silver, platinum, stainless steel, titanium, copper, aluminum and other metals and their alloy materials. It has been widely used in aviation, machinery, electronics, communication, power, chemical industry, automobile manufacturing, colleges and scientific research institutes. Maximum welding penetration ≤ 1.5mm (stainless steel material). Welding seam width 0.2-0.6mm.
5.Marking Sample
6.Our Company
7.Our Factory
8.Exhibition
