• Model NO.：FLC1325
• Cooling System：Water Cooling
• Technical Class：Continuous Wave Laser
• Applicable Material：Nonmetal
• Structure Type：Gantry Type
• Laser Classification：Gaseous Laser
• Laser Technology：Laser Control Fault Cutting
• Working Area：1500*3000mm or 1300*2500mm
• Laser Power：80W-300W
• Miq：1 PC
• Transport Package：Wood Crate
• Specification：1325,1530
• Trademark：FLYING
• Origin：China
• HS Code：8456110090
• Production Capacity：100PCS,Month
• Package size per unit product：375.00cm * 216.00cm * 138.00cm
• Gross weight per unit product：960.000kg

Basic Info.

Model NO. FLC1325 Cooling System Water Cooling Technical Class Continuous Wave Laser Applicable Material Nonmetal Structure Type Gantry Type Laser Classification Gaseous Laser Laser Technology Laser Control Fault Cutting Working Area 1500*3000mm or 1300*2500mm Laser Power 80W-300W Miq 1 PC Transport Package Wood Crate Specification 1325/1530 Trademark FLYING Origin China HS Code 8456110090 Production Capacity 100PCS/Month

Packaging & Delivery

Package size per unit product 375.00cm * 216.00cm * 138.00cm Gross weight per unit product 960.000kg

Product Description

Wood cnc laser cutter co2 laser cutting machine 1325
Features:

    This laser cutter machine is the latest design with 150W-300W laser tube, it can cut metals such as stainless steel,carbon steel, also can cut non-metal such as acrylic,wood/MDF,leather, foam, plastic and etc. It is equipped with advanced laser controlling system with auto focus, if the metal sheet is not flat, the system can sense the distance from the nozzle to the material surface and follow the surface up and down to automatically adjust the certain focus distance to keep the highest precision cutting quality.

Application materials:
Stainless steel, carbon steel, Wood, bamboo, jade, ceramic, textile, garments, crystal, plastic, Color plates, Plexiglas, glass, acrylic, wood, paper, leather, cloth, rubber, marble, granite, tiles, shells and other non-metallic materials.

Application industries:

Mainly used for advertising industries ( stainless metal and carbon steel ), sheet metal industry (carbon steel ), packaging  industry (die board )and so on . steel industries,Plastic and rubber industry, ads/crafts/presents industry. Strumpet/machine components, leather cloth industry. Advertising logo signs, gifts, crystal ornaments, paper cutting techniques, relief, wood carving Jane. Printing plate, leather clothing, embroidery, decoration, frame making and other industries.

Spcifications:

Model	FLC1325/FLC1530
Laser-type	10.6um CO2 glass laser tube w/ water-cooling
Laser power	80W-300W
Working area	1300*2500mm or 1500*3000mm
Max Engraving speed:	0-50, 000mm/min
Max cutting speed	0-24, 000mm/min
Laser output control	1-100% software setting
Location precision	Less than 0.01mm
Highest scanning precision	2500DPI
Operating temperature	0 - 45
Operating humidity	5- 95% non-condensing
Minimum shaping character	English 1.0 x 1.0mm
Graphic format supported	HPGL, BMP, JPEG, PLT, DST, DXF, and AI ...
Driving system	Stepper
Cooling mode	Water-cooling and protection system
Auxiliary equipments	Exhaust-fans, air-exhaust pipe, air pump, chiller
Controller	DSP
Compatible Software	CorelDraw, AutoCAD, Photoshop, TAJIMA
Slope Engraving	Can be easily designed within the "Grade Engrave" function.
Color separation	Uses color property to set function, speed, and laser power

Applicable materials:

wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.

Applicable industries:
advertisement, arts and crafts, shoes, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry.

Samples Show:
