Pedb-500 Safety Closured 50W 110X110mm Fiber Laser Marking Machine

Perfect Laser (Wuhan) Co., Ltd.
  • After-sales Service：on Line
  • Warranty：12 Months
  • Laser Visibility：Visible
  • Applicable Material：Metal and Non-Metal Material
  • Cooling System：Air Cooling
  • Technical Class：Continuous Wave Laser

Base Info

  • Model NO.：PEDB-500
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Solid Laser
  • Type：Optical Fiber Laser Marking Machine
  • Marking Method：Scanning Marking
  • Product Name：Laser Marking Machine
  • Certification：CE, FDA, ISO
  • After Sales Service Scope：Overseas
  • Application：Marking on Metal and Some Hard-Non Metal
  • Material：Stainless Steel, Aluminum, Cooper, Ect.
  • Diode Lsaer Module：USA Imported Name Brand
  • Q Switch：Famous British Brand
  • Transport Package：Wooden Case
  • Specification：ISO 9001 & CE&FDA
  • Trademark：Perfect Laser
  • Origin：China
  • HS Code：8456100090
  • Production Capacity：500 Sets, Month

Description

Q-switched operation

Output power adjustment range

10%-100%

Nominal average output power

20W

Central emission wavelength

1060-1070 nm

Emission Bandwidth (FWHM)

<10 nm

Long-term average power instability

<5%

Pulse width, (FWHM)

100 ns

Laser switching ON time

180 μsec

Laser switching OFF time

180 μsec

Pulse Repetition Rate* kHz

20-80 kHz

Energy per pulse (PRR = 20 kHz)

0.95 mJ

Typical beam quality, M2

<1.8

Output fiber delivery length

3m

Operating voltage

220V

Max. Power consumption

0.5 kw





Company Information:
Perfect laser Co. Ltd. (China) was founded in 1995, located in the core area of "China Optic Valley" - Wuhan city. Occupied with 3000 m2 ground, including R&D building and production area. It has more than 180 employees, most of them are with a bachelor degree or even a doctorate degree. Executed by reliable quality and reasonable price, our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries such as the USA, Italy, Korea, Singapore, Poland, Turkey, Sweden, Saudi Arabia to worldwide.
