Fiber Laser Marking Engraving Machine for Metal
Zhejiang Holy Laser Technology Co., Ltd.- Laser Visibility：Visible
- Applicable Material：Metal
- Cooling System：Air Cooling
- Technical Class：Continuous Wave Laser
- Laser Wavelength：Fiber Laser
- Laser Classification：Semiconductor Laser
Base Info
- Model NO.：HSGQ-20W
- Type：Optical Fiber Laser Marking Machine
- Marking Method：Scanning Marking
- Power：Small Power
- Drive Type：AC Servo Drive
- Engraving Machine Type：Laser Engraving Machine
- Current：AC
- Laser Type：Fiber Laser
- Usage：Metal
- Certification：SGS, Ce, FDA, TUV
- Transport Package：Wooden Case
- Specification：CE, FCC, FDA, SGS
- Trademark：holy laser
- Origin：China Zhejiang
- HS Code：8456110090
- Production Capacity：1000PCS,Year
Description
Model NO.
HSGQ-20W/30W/50W/100W
Wavelength
1064±10nm
Output power
20W/30W/50W/100W
Marking area
110*110/150*150/175*175/300mm(optional)
Marking depth
≤0.2mm(depending on material and marking area)
Marking speed
≥7000mm/s
Min.line width
0.01mm
Min.character size
0.15mm
Cooling
Air cooling
Location
Red location
Power supply
AC110V±10%Hz or AC220V±10%50Hz
Specifications:
1 Standard wall plug operation and high electrical efficiency
2 Air cooling
3 It can mark colorized
4 High quality focusable beam
5 High repetition rate
6 Optimized pulse duration
7 Exceptionally high reliability
8 Maintenance-free operation
Packaging and shipping:
After-sales service:
1. Two years warranty period
2. No-maintenance, life long time technical support, software update and laser part replaced in low price.
3. Laser part can continue work more than 20, 000 hours. Normally can be used more than five years.
4. Free design of fixtures as customers required.
5. Training your staffs to operate machine for free.
6. Design samples according to customers'culture image provided.
Company information:
ZheJiang Holy Laser technology Co.LTD has worked hard to become the global leader in manufacturing of laser equipment. All our products has passed the CE, FCC, SGS, TUV and FDA special for American market. 2012, company has obtained 6 patents certificate for computer software technology. Holy laser has been in the laser business since established. We strive to update our technology in the direction of green, environment-friendly and energy saving. review the past Holy Laser won market recognition step by step.looking for ward the future, Holy Laser will continue to dedicate our company mission and ethnic spirit with you to open a new chapter in history.
Trade Terms:
1, Payment: By L/C or T/T etc, and you can contact us.
2, 100% payment if the total amount less than 10000$, 30% deposit and 70% balance before shipment.
3, Lead time: 7-10 working days.
4, MOQ: 1set
