Fiber Laser Engraver Machine on Metal Ear Tag Plastic
Perfect Laser (Wuhan) Co., Ltd.- Laser Visibility：Visible
- Applicable Material：Metal and Nonmetal
- Cooling System：Air Cooling
- Technical Class：Continuous Wave Laser
- Laser Wavelength：Fiber Laser
- Laser Classification：Free Electron Laser
Base Info
- Model NO.：PEDB-400B
- Type：Optical Fiber Laser Marking Machine
- Marking Method：Scanning Marking
- Model No：Pedb-400b
- Computer：Not Includes PC
- Ipg Series：Pulsed, High Energy Ytterbium Fiber Lasers
- Mode of Operation：Pulsed
- Polarization：Random
- Nominal Average Output Power：10W - 30W for Pedb-400A ,400b ,400c 10W - 50W for
- Emission Bandwidth (Fwhm)：<10 Nm
- Long-Term Average Power Instability：<5%
- Pulse Width(Fwhm)：100 Ns
- Laser Switching on Time：180 μsec
- Transport Package：Wooden Case
- Specification：ISO9000 & CE
- Trademark：Perfect Laser
- Origin：China
- Production Capacity：300 PCS , Month
Description
Fiber laser marking machine details:
Perfect Laser's high quality fiber laser marking machine adopts international most advanced technology and the laser source is fiber with USA IPG technology, lifetime can reach 100,000 hours, 8-10 years without any consumables and maintenance. The diode coupling with fiber to process pump, the pump light will course the particles reverse which can emit high quality laser beam. This is the best choice for the customers who have special requirements to the smallest & finest laser beam and character.
Compact: The high-tech product, which is combined of laser device, computer, auto controller and precision machinery. It is small design and the complete weight is 160 kgs.
High Precision: Re-position precision is 0.002mm
High Speed: Imported scanning system makes the scanning speed is up to 7000mm/s
Easily Operating: Afford the specific marking software based on Windows, which is real-time adjust the laser power and pulse frequency. You can input and output by computer according to edit in the both of the specific marking software and the graphic software such as AutoCAD, CorelDRAW or Photoshop.
High Reliability: MTBF>100,000 hours
Energy Saving: The efficiency of optic-electrical converting is up to 70%
Low Running Cost: No wearing part. Free maintaining, no need to adjust the laser path.
Perfect Laser was founded in 1995, located in Wuhan city. We have 20 years experience in this field more than 180 countries and areas.
