• Model NO.：FLC2050C
• Laser Technology：Laser Control Fault Cutting
• Working Area：2.3m*5m
• Laser Power：100W
• Feeding Way：Auto Feeding
• Delivery Time：in 15 Days
• Transport Package：Plywood
• Specification：2050
• Trademark：FLYING
• Origin：China
• HS Code：8456100090
• Production Capacity：50PC,Month

Basic Info.

Model NO. FLC2050C Laser Technology Laser Control Fault Cutting Working Area 2.3m*5m Laser Power 100W Feeding Way Auto Feeding Delivery Time in 15 Days Transport Package Plywood Specification 2050 Trademark FLYING Origin China HS Code 8456100090 Production Capacity 50PC/Month

Product Description

Garment Fiberglass fabric leahter Laser Cutting Machine with Auto Feeding System
Features:
    The auto-feeding laser cutting machine is designed for cutting fabric, leather,cloth,paper and other soft materials in rolls, which largely enhances the working efficiency and saves time.
    It can be equipped with one, two or four cutting heads and auto feeding system, two or four cutting heads working at the same time. The feeding system can load materials by itself which can save the labor force and cut the cost.
    This machine is especially suitable for the mass processing of textile and garment.The machine can cut any curve fast and consecutively. DSP control system makes users can complete the mass production without the connection to the computer.
    We can make other sizes according to your requirements.

Specifications:

Effective working area	2.3*5m
Laser Type	Co2 sealed-off laser tube
Laser tube power	100w-150w
Working table	SUS304 stainless steel strip auto feeding working table
Automatic deviation correcting	With
Driver mode	3 phases stepper motor and Driver, Yako brand
Guide rail	Linear square guide rail ( Hiwin,Taiwan)
Transmission	Belt transmission
Control panel	English
Laser output control	1-100% software setting
Engraving speed	0-60000mm/min
Cutting speed	0-10000mm/min
Control system	RuiDa 6442 ( supporting automatic feeding)
Control software	RDWorks V8
Design software when delivery	CorelDraw, AutomCad, PhotoShop
Control panel	DSP offline
Resolution accuracy	< 0.01mm
Location precision	< 0.01mm
Highest scanning accuracy	2500DPI
Type of cooling	Industrial chiller CW-5000
Water protection system	Yes
Blow-off system	Air pump for the laser head Air blower for the machine
Upper smoking	Has
Biggest scanning accuracy	2500DPI
Working temperature	0-45 °C
Operating humidity	5-95% (without condensed water)
Voltage	AC 220V /110V, 50/60Hz, single phase
Supporting picture format	PLT,DST,DXF,BMP, DWG,AI,LAS,etc
Certificate	CE

Application Industry:
  Engraving and cutting of fabric and leather in garment, embroidery, toy, handbag, glove precision cutting of decoration board and non-mental board, like acrylic and MDF board in ads, upholstery, electrical appliance and plastic industry, cardboard box industry, rubber printing plate engraving. Ultra-thick material surface carving.
