• Model NO.：HR-SCW3000
• Laser Classification：Optical Fiber Laser
• Type：Portable Welding Machine
• Weight：150kg
• Dimension：1100X620X1100mm
• Power Demand：220V,50Hz
• Laser Device：Raycus
• Laser Power：3000W
• Welding Depth：3mm
• Cooling：Water
• Laser Wavelength：1064nm
• Maximum Input Power：14kw
• Spot Diameter：0.3mm-0.8mm
• Transport Package：Standard Export Plywood Cases
• Specification：1100x620x1100mm
• Trademark：HAIRONG
• Origin：China
• HS Code：8515809090
• Production Capacity：500units,Month

Laser Power

3000W

Maximum Input Power

14KW

Laser Medium Nd

Optical Fiber

Laser Wavelength

1064 nm

Rated laser output power

300~1000 W

Laser power instability

≤ ±2.5%

Spot Diameter

0.3 mm - 0.8 mm

Pulse Width

0.2 ms - 20 ms

 Pulse Frequency

1 Hz - 150 Hz

Welding Depth

1-2mm

Positioning Accuracy

0.02 mm

Repeat positioning accuracy

±0.01mm

Cooling

Circulating Water Cooling

 Power Demand

220V/50HZ

Dimension

1100x620x1100mm

Weight

150kg

1). Stable laser energy and good beam mode.
2). It has high aspect ratio, small weld width, small heat affected zone, small deformation and fast welding speed.
3). It is combined with computer technology and uses CNC automatic operation.
4). It is of high precision, high efficiency, low processing noise and has no pollution to the environment.
5). It has the function of automatic protection by current interruption in the case of misoperation and over temperature.
