• Model NO.：LSF30W
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Fiber Laser：Raycus
• Comtrol System：Jcz
• Operation System：Microsoft Windows 7. 8. 10 System
• Power Supply：220V,60Hz,8A(110V,60Hz,15A Can Choose)
• Transport Package：Wood Boxes
• Specification：working size: 110*110mm
• Trademark：Lansen
• Origin：China
• HS Code：8456110090

Graphic  format  supported

BMP,JPG,JPEG,GIF,TGA,PNG,TIF,TIFF

AI, PLT,DXF,DST,SVG,JPC,NC,G,BOT,GBR

Working  area

110mm*110 mm(Standard)

can choose 50*50 150*150 175*175 200*200 (mm)

If use rotary device, the max support 150x150mm field lens.

Marking  depth

<1mm

Marking  speed

<5000mm/s

Min. line  width

0.05mm

Repeatability  accuracy

0.003mm

Power  Machine

300-600W

Operation  temperature

0~40°C

Operation  system

Microsoft Windows system

Worktable size

380x265mm

Machine size

840mm*460mm*820mm

Grosse weight

92kg

 Features:

1. Fiber laser, Basic model, high speed galvo scanner; IPG laser and Chinese Brand laser for option.
2. Maintenance Free, save equipment and worker cost;
3. Imported Galvonometer, Higher precision,faster speed;
4. Higher photoelectric conversion efficiency,  Low power consumption;
5. Red light preview, more accurate and reduce positioning time;
6. Laptop with Powerful marking software;
7. User friendly software interface, easy operation;
8. Set and deal different layers graphic separately;
9. Support PLT,PCX,AL,DXF, BMP,JPG formats file;
10. Compatible AutoCAD,CorelDraw,Photoshop etc software, Automatic serialization,date coding letter, symbol, pattern, figure, image, bar code, 2D code  auto  arrangement and amendment.

Machine details:




Applications:


Aplicable Industries:
1. Electrical Engineering and Electrical part and component
2. Mobile (Cover, battery, keyboard, Phone Case)
3. Jewelry(Ring, pedeant, bracelet),eyeglass,clocks and craft
4. Building materials,PVC pipe
5. Car motor car spare part, Instrument and meters and cutting tool
6. plastic case,aviation and aerospace,
7. hardware fitting and accessory,sanitary appliance
8. food and beverage ,Medicine package and medical instrument,solar Pv industry
Applicable Materials:
1.Many type of metals: Gold,Silver,Stainless Steel,Copper,Aluminum,chrome Brass,etc
2.Alloy and metal oxides: Anodized Aluminum
3.Some non-metallic materials & Special surface treatment:
   silicon wafer, Poly,urethane, ceramics, plastic, rubber, epoxy resin, PVC, PC, ABS, Coating film etc.

Warranty:

1. 24 Months for Machine
2.  Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material.
3.  Lifely and fast technical guide and solution within 24hours by email and web camera.

About us:



FAQ

Q: Are you a factory or trading company?
A: We are a manufacturer, we own our exporting rights.

Q: Where are you located? How can we visit you?
A: We locates in Jinan of Shandong, as long as you give us and email or telephone, tell us your visit plan, we will arrange all for you in Jinan.

Q: How can I choose suitable machine?
A: Please communicate with us via inquiry or email, we can guide you. Please kindly tell us:
1) .What work table size you will need?
2).What work you will do?

Q: What's your payment terms? Delivery time and MOQ?
A: We accept T/T(bank transfer), L/C, Paypal, ESCOW, West union etc. Usually we need 30%
as deposit, balance paid before shipment.
Delivery Time: 7-10 days after payment
MOQ: 1set

Q: If I bought a machine, how could you make it safe while shipping.
A: We have a professional package suitable for oversea transpotation. Machine will be fixed well in the case.

Q: What's your quality control system?
A: All machines will be tested after finished. We have QC department response for this job. And we already got CE approved.

Q: What's your after-sales service?
A: 1) Warranty 2 years for whole machine.
2) Engineers available service machinery overseas
3) Full operator training

Q: If I don't know how to use the machine, can you teach me?
A: 1) There is a DVD disc including machine user manual and software user manual c/w machine
2) Online (skype & phone)
3) Remote desktop software (Team viewer)
4) Demo Video

Q:This is my first time buy machine from China, how i buy machine from you?
A:Choose suitable machine through talking with our seller manager → Pay to us→ manufacture and testing machine (about 5-7 workdays) →shipping to you
