• Model NO.：FLC9060
• Laser Classification：Gaseous Laser
• Engraving Method：Vector Engraving
• Working Area：900*600mm
• Control：CNC
• Laser Type：CO2
• Laser Power：60 W-150W
• Transport Package：Wood
• Specification：9060
• Trademark：Flying
• Origin：China
• HS Code：8156100090
• Production Capacity：100PC,Month

Basic Info.

Model NO. FLC9060 Laser Classification Gaseous Laser Engraving Method Vector Engraving Working Area 900*600mm Control CNC Laser Type CO2 Laser Power 60 W-150W Transport Package Wood Specification 9060 Trademark Flying Origin China HS Code 8156100090 Production Capacity 100PC/Month

Product Description

China factory cnc laser engraving and laser cutting machine 9060




Features:
    This machine adopts imported linear guide and DSP control system. The machine has stable performance and applicable for different industries.  It is the ideal choice for non-metal processing industry. Equipped with three-phase motors and drivers, belt can move in faster cutting speed and higher precision.

 Specifications:

Model	FLC9060
Laser-type	10.6um CO2 glass laser tube w/ water-cooling
Laser power	60W-150W
Working area	900*600mm
Max Engraving speed:	0-64, 000mm/min
Max cutting speed	0-30, 000mm/min
Laser output control	1-100% software setting
Location precision	Less than 0.01mm
Highest scanning precision	2500DPI
Operating temperature	0 - 45
Operating humidity	5- 95% non-condensing
Minimum shaping character	English 1.0 x 1.0mm
Graphic format supported	HPGL, JPEG, BMP, PLT, DST, DXF, and AI ...
Driving system	Stepper(Optional: Servo)
Cooling mode	Water-cooling and protection system
Auxiliary equipments	Exhaust-fans, air-exhaust pipe, air pump, chiller
Controller	DSP
Compatible Software	CorelDraw, AutoCAD, Photoshop, TAJIMA
Slope Engraving	Can be easily designed within the "Grade Engrave" function.
Color separation	Uses color property to set function, speed, and laser power

Applicable materials:
wood, organic glass, plastic, garments, paper, leather, foam, rubber, tile, and other nonmetal materials.

Applicable industries:
advertisement, arts and crafts,shoes,toys, computerized embroidery and clipping, garments,model and construction industry.

Cutting Thickness:

Materials	60w	80w	100w	130w	150w
Acrylic	8mm	15mm	15mm	20mm	20mm
Leather Cloth	One layer	Two layer	Two layer	Three layer	Three layer
Wood	5mm	8mm	10mm	15mm	15mm
Paper	3mm	6mm	8mm	8mm	8mm
Plastic	4mm	5mm	5mm	7mm	7mm
Rubber	2mm	2mm	2mm	2mm	2mm
PVC	3mm	6mm	8mm	8mm	8mm
MDF	3mm	6mm	8mm	10mm	10mm
Plywood	6mm	10mm	12mm	15mm	18mm

Samples Shown:
