90 Three Jaw Laser Machine Tube Cutting Pneumatic Round Tube Feeding Chuck
Foshan Nanhai Haiyu Electromechanical Industry Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Textile Machinery, Automotive Industry, Advertising Industry
- Cooling System：Air Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
Base Info
- Model NO.：JD90
- Structure Type：Gantry Type
- Laser Classification：Solid Laser
- Laser Technology：Laser Fusion Cutting
- Transport Package：Wooden Box
- Origin：China
- HS Code：843143100
- Production Capacity：1000
Description
Product Description
Pneumatic built-in structure, no need to install rear rotary cylinder;
Clamping accuracy 0.05-0.08mm (10mm from the end face);
Strict dust-proof design to confirm the service life of the protection bearing;
Simple structure, high efficiency and low cost design;
Aluminum alloy cylinder body, light weight, heat dissipation effectively reduce the temperature.
Application
The pneumatic rotary type front chuck is suitable for the improvement of CNC lathes, ordinary lathes, instrument cars and equipment that needs to be rotated. The middle of the chuck is designed with a through hole, which can be processed through long bars.
The chucks and fixtures developed by the company are widely used in the aerospace, textile machinery, medical equipment, fitness equipment, auto and motorcycle accessories, laser cutting, petrochemical machinery, agricultural machinery, other civil machinery and other fields.
Use Cases
| Type | JD40 | JD70 | JD90 | JD120 |
| A | 95 | 136 | 136 | 168 |
| B | 65 | 105 | 105 | 140 |
| C | 48 | 68 | 90.5 | 120.5 |
| D | 155 | 155 | 190 | 190 |
| E | 192 | 192 | 230 | 235 |
| F | 172 | 172 | 210 | 210 |
| G | 5 | 5 | 6 | 6 |
| H | 20 | 20 | 23 | 20 |
| I | 212 | 227 | 236 | 285 |
| J | 125 | 140 | 148 | 166 |
| Mounting screws | 3H-M10 | 3H-M10 | 3H-M12 | 3H-M12 |
| Max speed | 1400 | 1400 | 800 | 600 |
| Working Pressure | 10/20kg/cm² | 10/20kg/cm² | 10/15kg/cm² | 10/15kg/cm² |
| ClampingFforc | 4032KGF@cm² | 5179KGF@cm² | 5913KGF@cm² | 6148KGF@cm² |
Package
RFQ:
Q: What can I get the price?
A: We usually quote within 2 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.
Q: What is your term of delivery?
A: We accept EXW, FOB Guangdong. You can choose the one which is the most convenient or cost effective for you.
Q: What about the lead time for the mass production?
A: Honestly, it depends on the order quantity and the season you place the order.
Q: Are you trading company or manufacturer ?
A: We are factory and trade company.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
