Galvo Head Laser Engraving Machine for Metal and Plastic Marking Barcode Text Brand Logo and Any Design
Dongguan Synutar Intelligent Equipment Co., Ltd.- After-sales Service:24 Hours 7 Days Online Service
- Warranty:1 Year Warranty
- Application:Printing & Packaging, Construction Industry, Molds & Dies, Advertising Industry
- Cooling System:Air Cooling
- Technical Class:Continuous Wave Laser
- Automatic Grade:Manual
Base Info
- Model NO.:SY-F20,SY-F30,SY-F50,SY-F70,SY-F100
- Applicable Material:Metal
- Type:Oscillating Mirror
- Laser Classification:Solid Laser
- Engraving Method:Vector Engraving
- Laser Source Type:Standard,Mopa
- Laser Marking Head:2-Axis,3-Axis
- Laser Power:20W,30W,50W,60W,70W,100W
- Marking Area:70X70,110X110,150X150,175X175,200X200(Optional)
- Marking Speed:Less Than 8000mm,S
- Supported Format:BMP,JPG,TIF,Pcx,Tag,Ioo,GIF,Plt
- Min. Character Size:0.15mm
- Min. Linear Width:0.01mm
- Cooling Mode:Air Cooling
- Power Consumption:Less Than 500W
- Transport Package:Plywood
- Trademark:SYNUTAR
- Origin:China
- HS Code:8456110090
- Production Capacity:600sets,Year
Description
Basic Info.
Model NO. SY-F20/SY-F30/SY-F50/SY-F70/SY-F100 Applicable Material Metal Type Oscillating Mirror Laser Classification Solid Laser Engraving Method Vector Engraving Laser Source Type Standard/Mopa Laser Marking Head 2-Axis/3-Axis Laser Power 20W/30W/50W/60W/70W/100W Marking Area 70X70/110X110/150X150/175X175/200X200(Optional) Marking Speed Less Than 8000mm/S Supported Format BMP,JPG,TIF,Pcx,Tag,Ioo,GIF,Plt Min. Character Size 0.15mm Min. Linear Width 0.01mm Cooling Mode Air Cooling Power Consumption Less Than 500W Transport Package Plywood Trademark SYNUTAR Origin China HS Code 8456110090 Production Capacity 600sets/YearProduct Description
Galvo Head Laser Engraving Machine for Metal and Plastic Marking Barcode Text Brand LOGO and Any DesignAdvantages of Machine:
High Precision: re-position precision is 0.003mmHigh Speed: imported scanning system makes the marking speed is up to 800 standard characters/s.Easily Operation: the marking operation system is based on Windows, and you can input words and graphs by marking and graphic software, such as Photoshop, AutoCAD, or CorelDRAW.High stability: the power stability is more or less 1% rms.Humanized Design: all of our fiber laser marking machine is equipped with a pedal, you can control laser on-off switch by pressing pedal instead of clicking the mouse.Low cost: the photoelectric conversion rate up to 38% to 50%, the laser system power is only few hundreds watts.Optical design
The unique backward reflecting isolation device can effectively prevent laser beam from entering theoscillatoragainandcause thedamage.
Mechanical design
Thelasersystemissmaller,fullyaircooling,fiberoutput,easily toinstallandoperate. Technical Data
Model | SY-F20/30/50/100 |
Laser Power | 20W/30W/50W/100W |
Power stability(8h) | <±1%rms |
Laser Wavelength | 1064nm |
Laser Frequency | 20Khz-100Khz |
Beam Quality | <1.5 M² |
Marking Area | 70mmx70mm/110mmx110mm/150X150mm 175X175mm/200mmX200mm/300mmX300mm(Optional) |
Marking Speed | ≤8000mm/s |
Supported Format | BMP,JPG,TIF,PCX,TAG,IOO,GIF,PLT |
Min. Charactersize | 0.15mm |
Min. Linear Width | 0.01mm |
Repeated Frequency | ±0.003mm |
Cooling Mode | Air cooling |
Supported format | BMP,JPG,TIF,PCX,TAG,IOO,GIF,PLT |
Environmental Temperature | 10ºC-35ºC |
Humidity | 5%-75% |
Power Consumption | <500W |
PowerVoltage | 220V±10%/50HZ/5A |
Life of Laser Module | 100000hours |
